Precision Liquid Level Monitoring with Rugged Reliability
The 52mm Blue Water Level Sensor combines vertical-mount design and magnetic reed-switch technology to deliver accurate, maintenance-free liquid level detection in demanding environments14. Certified to CE/ROHS/REACH standards, this IP67-rated sensor ensures compliance with global industrial safety and environmental regulations.
Key Specifications
- Diameter: 52mm (compact for tight installations)
- Switch Type: Magnetic reed switch (NO/NC configurable)
- Protection: IP67 waterproof housing (submersible up to 1m)
- Material: PP/POM corrosion-resistant body
- Voltage: 12–250V AC/DC (universal compatibility)
- Temperature Range: -20°C to +80°C
- Wiring: 2m PVC cable (custom lengths available)
Engineering Advantages
Smart Vertical Alignment
- Vertical mounting eliminates debris accumulation, ideal for tanks, sumps, and reservoirs.
- Magnetic actuation ensures contactless switching, reducing mechanical wear
Industrial-Grade Resilience
- PP/POM housing resists chemicals, oils, and UV degradation14.
- Sealed epoxy encapsulation protects internal circuits from humidity and condensation.
Plug-and-Play Integration
- SPDT relay outputs (1A @ 250V AC) interface seamlessly with PLCs, pumps, and alarms.
- Pre-calibrated for water, glycol, and light oils (custom thresholds upon request).
Typical Applications
| Industry | Use Case |
|---|---|
| HVAC | Condensate tank overflow prevention |
| Water Treatment | Chemical dosing pump activation |
| Food Processing | Stainless-steel variant available for sanitary environments |
| Agriculture | Irrigation system level control |
Why Choose This Sensor?
- Multi-Certification Assurance: CE/ROHS/REACH compliance simplifies export and procurement.
- Cost Efficiency: 100,000+ cycle durability minimizes replacement costs.
- Customization: Optional M12 connectors, 304SS housings, and explosion-proof designs.
