This series of IP67 waterproof metal tactile switches comes in 12/16/19/22mm sizes with multiple LED options including dual-color, tri-color and RGB multicolor illumination. Perfect for modern control interfaces requiring both durability and visual customization.
| Mounting Size | 12mm / 16mm / 19mm / 22mm |
| Switch Type | Metal Tactile Switch |
| Protection Grade | IP67 Waterproof |
| Operation Type | Momentary (Self-reset) |
| Contact Type | NO (Normally Open) |
| Light Option | Illuminated / Non-Illuminated |
| LED Type | Ring / Ring + Power |
| LED Color | Dual-Color / Tri-Color / RGB Multicolor |
| Head Type | Flat |
| Contact Material | Silver Plated |
| Connection | Crimping |
| Bezel | Metal |
| Shell Material | Metal |
| Application | Control Panel, Automotive, DIY, Industrial Equipment |
This 12/16/19/22mm IP67 waterproof metal tactile switch provides excellent durability and customization. IP67 waterproof rating ensures stable performance in damp, outdoor and harsh environments. It supports rich lighting options including dual-color, tri-color and RGB multicolor LED for visual status indication and personalized design. The momentary tactile design offers sensitive and clear feedback. High-quality metal structure and silver-plated contacts ensure long service life and stable electrical performance.
1. What sizes does this tactile switch support?
It supports 12mm, 16mm, 19mm and 22mm standard mounting sizes.
2. Is this switch IP67 waterproof?
Yes, it has IP67 high-level waterproof and dustproof protection.
3. What LED colors are available?
It supports dual-color, tri-color and RGB multicolor LED options.
4. Is it momentary type?
Yes, it is momentary (self-reset) tactile switch with NO contact.
5. Are non-illuminated versions available?
Yes, both illuminated and non-illuminated types are optional.
| Bezel | |
|---|---|
| Connection | |
| Contact Material | |
| Head Type | |
| Lamp | |
| Lamp Type | |
| LED Color | |
| Operation of Contact |
There are no reviews yet.
