This 16mm metal push button switch features an anodized aluminum button in black, red, or blue, with a custom symbol option for clear function identification. Designed for 12V systems, it offers a durable and stylish solution for control panels, industrial machines, and electronic devices.
Contact Resistance | ≤50mΩ |
Insulation Resistance | ≥1000mΩ |
Dielectric Strength | 1000VAC min |
| Protection Levels | IK10 |
Ambient Temperature | -30℃~+80℃ |
Waterproof | IP65/IP66 |
| Pins | H65 / H65 Silver Plated / Gold |
| Nut | Nickel brass |
This 16mm custom symbol metal push button adopts high-grade aluminum oxidation craftsmanship with black, red and blue color options. Custom engraved symbols make equipment function clearer and more recognizable. It supports multiple LED colors and wide voltage from 3V to 220V, compatible with most electrical systems. Momentary and latching dual working modes meet different control requirements. Multiple shell materials and 5Pin/7Pin terminals can be freely matched. IP65 waterproof and IK10 impact resistance adapt to industrial workshop and complex indoor environments with stable and long-lasting performance.
1. What is the mounting size?
Standard 16mm mounting hole diameter.
2. Color options?
Aluminum oxidation black, red and blue optional.
3. LED and voltage customizable?
Multiple LED colors, voltage range 3V to 220V optional.
4. Pin options?
5Pin and 7Pin terminal for different circuit needs.
5. Waterproof and impact grade?
IP65/IP66 waterproof, IK10 high impact resistance.
| Connection | |
|---|---|
| Contact Material | |
| Operation of Contact | |
| Position | |
| PIN Material |
