Key Features

• 16mm standard mounting hole size
• Momentary self-reset operation type, no locking
• 1NO normally open contact configuration
• Tri-color RGB ring LED: Red / Green / Blue
• Standard 12V LED voltage, multi voltage customizable
• Elegant flat round head for seamless panel mounting
• 6 pin terminals with common positive design
• Premium nickel plated brass housing corrosion resistant
• Waterproof structure for indoor and outdoor use
• LED lifespan up to 40000 hours soft brightness
• Mechanical life 1,000,000 times, electrical life 50,000 times
• Low contact resistance ≤50mΩ, insulation resistance ≥50MΩ
• Wide working temperature: -20℃ ~ +55℃
• Silver alloy contact stable conduction and long service life

Product Advantages

This 16mm 1NO momentary metal push button is built with tri-color RGB ring LED, supporting red, green and blue color switching for rich status indication. Adopting flat round head and nickel plated brass shell, it is wear-resistant, anti-corrosion and exquisite in appearance. Pure momentary self-reset design is perfect for one-touch trigger control. With 6-pin common positive terminal, wiring is simple and convenient. Excellent electrical parameters and long mechanical & electrical lifespan ensure stable long-term operation, suitable for vehicle modification, industrial panel and DIY electronic projects.

Applications

• Automotive interior multi-function RGB control switch
• Industrial equipment status indicator button
• Smart device and control panel illumination switch
• DIY computer case chassis modified button
• 12V electronic system and instrument control
• Waterproof indoor equipment and customized control projects

FAQ

1. What is the mounting size?
Standard 16mm mounting hole diameter.

2. Does it support RGB tri-color?
Yes, built-in red / green / blue three-color ring LED.

3. What operation type is it?
Momentary self-reset type, press to on, release to off.

4. LED voltage customizable?
Standard 12V, support 3V/5V/24V/110V/220V custom.

5. How many pins?
6 pin terminals with common positive design for easy wiring.
