Key Features

• Standard 22mm mounting size for universal industrial panel installation
• Plastic bezel and full plastic shell, lightweight and cost-effective
• Red rotary head type, clear emergency identification
• Non-illuminated design for conventional control application
• Dual operation mode: Maintained Latching / Momentary Self-resetting optional
• High 10A rated current for heavy load emergency shutdown
• Multiple contact combinations: 1NO+1NC, 2NO, NO, NC
• Silver contact material, stable conduction and long service life
• Simple rotary reset structure, easy operation and installation
• Ideal for industrial equipment emergency power off and safety control

Technical Specifications

Product Attributes

• Bezel: Plastic
• Shell Material: Plastic
• Head Type: Rotary
• Head Color: Red
• Lamp: Non-Illuminated
• Contact Material: Silver
• Contact Operation: 1NO+1NC , 2NO , NO , NC

Product Advantages

This 22mm plastic E-stop button adopts lightweight plastic shell and red rotary head design. It supports both maintained latching and momentary working modes, with high 10A current rating for industrial heavy load emergency shutdown. Multiple contact combinations meet various circuit design requirements. Silver contact ensures stable electrical performance, non-illuminated structure is simple and practical, easy to install and operate, perfect for all kinds of industrial equipment safety emergency stop control.

Applications

• 22mm panel plastic rotary E-stop emergency button
• Industrial equipment 10A high load emergency shutdown switch
• Mechanical cabinet non-illuminated red emergency stop button
• Automation panel maintained momentary dual mode safety switch
• Cost-effective plastic emergency control push button

FAQ

1. Mounting size?
Standard 22mm mounting hole.

2. Operation mode?
Support maintained latching and momentary self-resetting two options.

3. Rated current?
10A high current rating.

4. Illumination?
Non-illuminated version.

5. Contact options?
1NO+1NC, 2NO, NO, NC multiple combinations available.
