Key Features

• Standard 22mm mounting hole for industrial panel standard installation
• Integrated waterproof structure adapts to dusty and humid workshop environment
• Red rotary head design, obvious identification for emergency operation
• Non-illuminated simple practical design for general safety control
• Dual operation mode: Maintained latching / Momentary self-resetting optional
• Fixed 1NO1NC contact combination to meet most industrial circuit needs
• Plastic bezel and plastic shell material, lightweight and cost-effective
• Silver contact material, stable conductivity and long service life
• Compliant with EN60947 and IEC60947-5-1 international safety standards
• High voltage withstand performance: AC-15 380V/220V, DC-13 220V/110V
• Rotary reset operation, simple and quick to restore normal work
• Professional emergency shutdown function for mechanical safety protection

Technical Specifications

Product Attributes

• Bezel: Plastic
• Shell Material: Plastic
• Head Material: Plastic
• Head Type: Rotary
• Head Color: Red
• Lamp: Non-Illuminated
• Contact Material: Silver
• Contact Operation: 1NO + 1NC

Product Advantages

This 22mm waterproof 1NO1NC emergency stop switch adopts full plastic structure with red rotary reset head. Built-in waterproof design can adapt to humid and dusty industrial workshops. It supports maintained latching and momentary two working modes, fixed 1NO1NC contact configuration, perfectly matching conventional safety control circuits. Comply with EN60947 and IEC60947-5-1 industrial safety standards, with stable AC and DC voltage load capacity. Simple rotary reset operation, cost-effective and durable, is the preferred safety component for standard industrial machinery and automation equipment.

Applications

• 22mm panel waterproof plastic emergency stop button for dusty humid workshop
• Industrial production machinery 1NO1NC non-illuminated safety switch
• Automation equipment control panel maintained & momentary E-stop button
• Packaging machinery, conveyor equipment emergency shutdown push button
• Electrical cabinet and mechanical equipment standard safety protection switch

FAQ

1. What is the mounting size?
Standard 22mm mounting hole size, suitable for conventional industrial panel installation.

2. Does it support dual operation modes?
Yes, both maintained latching and momentary self-resetting types are available.

3. What is the contact configuration?
Fixed 1NO1NC contact combination, suitable for most safety control circuits.

4. Is this emergency button waterproof?
Yes, it adopts waterproof construction, suitable for humid and dusty workshop environments.

5. Does it follow international industrial standards?
Yes, it complies with EN60947 and IEC60947-5-1 safety standards.

6. Is it illuminated type?
No, this model is non-illuminated version with pure mechanical control.
