Characterized by a unique operating structure, the operation is instantaneous and soft, reliable gold and silver plated contacts are used, and the service life is long. The push button switch has a surrounding enclosed structure, which is safe, reliable, and easy to connect.
| Technical Parameter: | |
| Working Temperature: | -5° – 40° |
| Wiring Ability: | Spiral embedded terminal, minimum wiring 1 * 0.5 square meters, maximum 2 * 1.5 square meters or 1 * 2.5 square millimeters |
| Rated Insulation Voltage: | Voltage 690V |
| Convientional Freeair Thermal Current: | 1th 10A, 6A (boxed) |
| Rating: | AC-15 ：220V/6A ；380V/4A ；500v/2A |
| DC-13 ： 24V/6A ；48V/3A； 110V/1A | |
| 220V/0.5A ；440V/0.25A | |
| Mechanical Life: | flat head and mushroom head and lamp head —–1 million times |
| other head— 500000 times | |
| Electrical Life: | flat head and mushroom head AC 500000 times; DC 200000 times, the remaining 50000 times |
| Protection Grade: | IP40 (IP65 waterproof button) |
| Compliant With Standards： | IEC60947-5-1 GB/T 14048.5 |
| Operation of Contact | |
|---|---|
| LED Color | Blue, Double Color, Green, Orange, Purple, Red, White, Yellow |
| Lamp Type | |
| PIN Material | |
| Head Material | Plastic, SUS |
| Length of Shell | |
| LED Pressure | AC 1.8V, AC 110V, AC 12V, AC 220V, AC 24V, AC 2V, AC 36V, AC 380V, AC 3V, AC 48V, AC 6V, DC 1.8V, DC 110V, DC 12V, DC 220V, DC 24V, DC 2V, DC 36V, DC 380V, DC 3V, DC 48V, DC 6V |
