Key Features & Core Advantages

• Standard 22mm mounting size, compatible with mainstream industrial control panels for easy installation
• Dual position options: 2P (2-position) and 3P (3-position) to meet diverse gear control demands
• Two operation modes: maintained (latching) and momentary (reset) for flexible circuit logic design
• Integrated waterproof structure, suitable for humid, outdoor and wet industrial working environments
• Illuminated design with 5 optional LED colors: Blue, Green, Red, White, Yellow for clear status indication
• Standard 1NO1NC (1 Normally Open + 1 Normally Closed) contact configuration for signal switching
• High-quality silver contacts, low contact resistance, excellent conductivity and anti-oxidation ability
• Crimp type connection terminal, fast wiring, firm connection, ideal for mass assembly
• Plastic bezel and plastic shell, lightweight, good insulation and impact resistance
• Rotary head design with comfortable operation feel and precise gear positioning
• Visual LED reminder, real-time display of switch working status, improve operation safety
• Compact overall structure, space-saving for control cabinets and field equipment
• Durable construction, long service life and low failure rate for long-term frequent use
• Universal design, widely applied to various industrial equipment around the world

Full Technical Specifications

Product Attributes

• Mounting Dimension: 22mm Standard Panel Mount
• Position: 2P / 3P Optional
• Operation: Maintained + Momentary Dual Modes
• Protection: Waterproof Performance
• Contact: 1NO1NC, Silver Material
• Wiring: Crimp Connection
• Main Material: Plastic (Bezel & Shell)
• Head: Rotary Type
• Light Feature: Illuminated LED
• LED Colors: Blue, Green, Red, White, Yellow
• Core Strength: Waterproof, Visual Status, Multi-mode Selection

Product Advantages

This 22mm illuminated waterproof rotary switch is a professional control component for humid and outdoor environments. The standard 22mm size matches most industrial panels, bringing great convenience for installation. It supports 2-position and 3-position gears, as well as maintained and momentary two working modes, which can adapt to complex circuit control requirements. The built-in waterproof structure effectively resists moisture and water splash, expanding the application range to outdoor and wet workshops. Equipped with multi-color LED indicator lights, the switch working status is clearly visible at a glance, which helps operators judge the equipment state quickly. Adopting silver contacts and 1NO1NC classic structure, it ensures stable current transmission. The crimp terminal simplifies wiring work and is suitable for batch production and on-site wiring. The all-plastic body has good insulation and shock resistance. With reliable quality and diverse configurations, this switch meets the usage standards of global markets and is a cost-effective choice for industrial equipment in special environments.

Application Scenarios

This waterproof illuminated rotary switch is exported to Europe, North America, Southeast Asia and other regions, specially designed for equipment in humid and outdoor conditions.

• Outdoor engineering machinery and field operation equipment control panels
• Wet workshop machines and food processing equipment gear switches
• Outdoor power distribution boxes and waterproof low-voltage control systems
• Marine auxiliary equipment and waterfront electromechanical control components
• Industrial automation devices with high humidity working conditions
• Commercial outdoor electrical appliances and waterproof function selector knobs

FAQ

1. What mounting size and position options does this switch have?
The standard mounting size is 22mm, and it is available in 2-position (2P) and 3-position (3P) versions.

2. What operation modes are supported?
It supports two operation modes: maintained (latching) and momentary (reset).

3. Does this switch have waterproof performance?
Yes, it is designed with waterproof structure, suitable for humid and outdoor working environments.

4. What is the contact structure and material?
It adopts 1NO1NC contact configuration, and the contact material is silver for stable conduction.

5. What type of terminal does it use for wiring?
The terminal is crimping type, which realizes fast and firm wiring connection.

6. Is this switch equipped with indicator lights? What colors are available?
It is an illuminated rotary switch; optional LED colors include Blue, Green, Red, White and Yellow.

7. What are the materials of bezel and shell?
Both the bezel and outer shell are made of plastic with good insulation performance.

8. What is the difference between maintained and momentary modes?
Maintained mode keeps the gear position after rotation; momentary mode will automatically reset when released.

9. What kinds of equipment is this switch suitable for?
It is widely used for outdoor machinery, humid environment equipment and industrial control systems worldwide.
