Key Features

• Full customized metal push button solution
• Multiple head styles: Flat Head / Raised Head / Ball Head
• Multi mounting size: 8/10/12/16/19/22mm
• IP65 waterproof and dustproof grade
• Dual function: Momentary self-reset / Latching self-locking
• Rated up to 10A 250VAC heavy duty
• Body material: Brass nickel plated
• Multiple pin options: 2/3/4/6 pin terminals
• LED color and voltage customizable (12V blue optional)
• Contact configuration: 1NO1NC / 2NO2NC optional

Product Advantages

This customized metal push button switch supports full personalized customization in size, head shape, LED color, voltage and pin definition. Available in flat, raised and ball head designs to match different panel aesthetics and installation needs. Multiple mounting diameters from 8mm to 22mm cover most standard panel holes. IP65 waterproof structure adapts to indoor and light outdoor environments. Both momentary self-reset and latching locking functions are optional, suitable for industrial equipment, home appliances and custom electronic projects.

Applications

• Custom industrial control panels
• Mechanical equipment and automation devices
• Home appliance and electronic product modification
• DIY electronic projects and custom cabinets
• Instrument panel and smart device control
• IP65 indoor and light outdoor equipment

FAQ

1. What head types are available?
Flat head, raised head and ball head for selection.

2. What mounting sizes do you support?
8mm, 10mm, 12mm, 16mm, 19mm, 22mm full range.

3. Does it support momentary and latching?
Yes, self-reset momentary and self-locking latching optional.

4. Is this switch customizable?
Yes, size, head shape, LED, voltage and pins all customizable.

5. What is the protection level?
IP65 waterproof and dustproof for daily industrial use.
