Key Features

• Standard 16mm mounting hole size for elevator panel installation
• Flat round head design, elegant and suitable for elevator appearance
• Dual operation type: Self-locking / Momentary optional
• Switch combination optional: 1NO1NC / 2NO2NC
• Ring LED illuminated type, clear working status indication
• Multiple LED voltage: 6V/12V/24V/110V/220V/230V customizable
• LED color: Blue, Red, Green, Yellow, White, Orange available
• 5 pin terminals & 2.8×0.5 connection terminal for wiring
• Rated switch specification: 3A / 250VAC
• Max contact resistance less than 50mΩ, stable conduction
• Insulation resistance ≥1000MΩ, dielectric intensity 2000VAC
• High protection grade: IP67 waterproof & IK10 impact resistance
• Wide ambient temperature: -20°C ~ +55°C
• Mechanical life over 500,000 cycles
• Electrical life over 50,000 cycles
• Panel thickness adaptable: 1~10mm
• Operation pressure 3~5N, operation stroke about 2.5mm
• Premium material: Nickel plated brass / Stainless steel / Silver alloy contact
• PA66 base material, sturdy and aging resistant
• LED service life up to 40000 hours
• Plug-in connection, silver PIN material anti-oxidation
• Delivery within 1-7 days after payment

Technical Specifications

Product Attributes

• Connection Mode: Plug in
• Contact Operation: 1NO+1NC / 2NO+2NC Optional
• Position Mode: Two Position Maintained , Two Position Momentary
• PIN Material: Silver

Product Advantages

This 16mm 230V LED metal push button is professionally developed for elevator and lift systems. It supports self-locking and momentary two working modes, with 1NO1NC / 2NO2NC multi-contact options. Adopting ring LED lighting design, multiple voltages and colors are optional, compatible with 230V elevator circuit. IP67 waterproof and IK10 impact resistant grade adapts to public high-frequency use. Made of nickel plated brass, stainless steel and silver alloy contact, it owns ultra-long mechanical, electrical and LED service life. Wide temperature adaption and 1~10mm panel thickness compatibility make it the ideal replacement button for elevator control panels.

Applications

• 16mm 230V elevator lift dedicated LED control button
• Commercial building elevator panel flat round head switch
• IP67 IK10 public facility high durability push button
• Industrial control cabinet 1NO1NC illuminated latching switch
• High-traffic environment long life metal push button replacement

FAQ

1. Mounting size?
Standard 16mm mounting hole for elevator panel.

2. Operation mode?
Self-locking and momentary two types optional.

3. LED voltage & color?
6V~230V multi voltage, blue/red/green/yellow/white/orange optional.

4. Protection grade?
IP67 waterproof + IK10 impact resistance.

5. Lifespan?
Mechanical life over 500k cycles, LED life up to 40000 hours.
