Push Button Switch IP67 IK08 5A Nickel Plated Brass/Stainless Steel/Aluminum 25mm Momentary/Latching Pin Terminal

Our premium 25mm push button switch delivers robust performance for industrial control applications. Available in nickel-plated brass, stainless steel, or aluminum housing, this durable switch features:

‌High Protection‌: IP67 waterproof & IK08 impact resistance ‌Versatile Operation‌: Momentary or latching action options ‌Reliable Contacts‌: 5A current rating with pin terminal connection ‌Industrial Durability‌: Corrosion-resistant metal construction

Ideal for control panels, machinery, and outdoor equipment requiring dependable switching in harsh environments. Custom configurations available upon request.

Enquiry
SKU:SCJ7M25FFCategory:
Description
Production namePush Button Switch
Max. Current5A
Max. Voltage250VAC
LEDNO
Whether the smart
NO
IP level
IP67   IK08
Mounting hole diameter25mm
Switch combination1NO1NC, 2NO2NC
Operation type
Momentary/Latching
Terminal typePin terminal
Symbol customizedAcceptable
Housing Material
Nickel plated brass/Stainless steel/Aluminum
Certification
CE

Product image
