Key Features

• 12mm standard mounting hole for mini panel installation
• Ultra short low profile design suitable for limited narrow space
• Classic flat head simple appearance comfortable pressing
• 1NO normally open contact simple and practical circuit design
• IP65 professional waterproof and dustproof protection grade
• Stainless steel housing rust-proof corrosion-resistant durable
• Light 2.5N operation pressure sensitive touch feeling
• Ultra short 0.5mm operation stroke quick response
• Super long mechanical life up to 1,000,000 times
• Electrical life ≥50,000 times stable long-term use
• Low contact resistance ≤50mΩ stable conduction
• Working temperature: -20℃ ~ +55℃ suitable for civilian equipment
• Pin terminal design convenient plug-in wiring
• Built-in switch module compact integrated structure

Technical Specifications

Product Advantages

This 12mm short mini micro metal push button adopts ultra-short low-profile structure, specially developed for narrow and limited installation space. Made of high-quality stainless steel shell, anti-rust and anti-corrosion with stable texture. Flat head design with 2.5N light operation pressure and 0.5mm short stroke, sensitive pressing and quick rebound. Standard 1NO normally open contact meets most basic trigger control needs. IP65 waterproof performance adapts to daily dust and splash environment. With up to 1 million times mechanical life and 50 thousand times electrical life, it is durable and cost-effective for mass equipment matching.

Applications

• Ultra-thin panel and limited space equipment button
• Mini instrument, meter and portable electronic device
• Automotive hidden modification and function control switch
• Smart home small electrical and embedded control panel
• Student electronic DIY and experimental circuit project
• 12mm hole short body micro button replacement

FAQ

1. What is the mounting size?
Standard 12mm mounting hole diameter.

2. What is special about this model?
Ultra short mini low profile design for narrow installation space.

3. Contact type?
1NO normally open configuration for basic trigger control.

4. Operation feeling?
2.5N light pressure, 0.5mm short stroke sensitive response.

5. Service life?
Mechanical life ≥1 million times, electrical life ≥50,000 times.
