• Standard 22mm mounting size, widely compatible with industrial control panels
• Dual operation modes: momentary and maintained for diverse control demands
• Flat head design, simple appearance and comfortable operation feeling
• Integrated waterproof structure, adapt to humid industrial working environments
• Classic 1NO+1NC contact configuration for universal circuit matching
• Silver contact material, excellent conductivity and long service life
• Plastic bezel and plastic shell, lightweight and cost-effective
• Built-in illuminated LED, available in 6 optional colors: Black, Blue, Green, Red, White, Yellow
• Complete electrical performance, suit for AC and DC circuit systems
• Compliant with CE, EN60947-5-1, IEC60947-5-1 and GB/T14048.5 standards
• Reliable performance, low failure rate for long-term continuous operation
• Easy installation and wiring, ideal for various industrial control equipment

Technical Specifications

Product Attributes

• Mounting Dimension: 22mm
• Operation Type: Momentary & Maintained
• Feature: Waterproof & Illuminated
• Head Style: Flat
• Bezel & Shell: Plastic
• Contact: Silver
• Contact Form: 1NO + 1NC
• LED Color: Black / Blue / Green / Red / White / Yellow
• AC Rating: 380V/220V, 4.5A
• DC Rating: 220V/110V, 0.6A
• Insulation Voltage: 660V
• Impulse Voltage: 2.5kV
• Thermal Current: 10A

Product Advantages

This 22mm flat illuminated push button switch supports both momentary and maintained operation modes to meet different control logic requirements. It adopts plastic overall structure and silver contacts, which ensures stable electrical conduction and cost efficiency. The waterproof design enables it to work normally in humid workshops and equipment cabins. Multiple LED colors are available for status distinction. With complete AC and DC electrical parameters, it covers most conventional industrial circuits. The product passes CE certification and complies with international and national electrical standards, featuring stable performance, long mechanical life and easy installation. It is a cost-effective control component for industrial automation and electrical equipment.

Applications

• Industrial control cabinet start, stop and function selection buttons
• Automation machinery equipment operation panel control switches
• Electrical equipment and power distribution box signal control components
• Production line equipment momentary jog and latching control system
• General electromechanical device waterproof operation and status indicator switch

FAQ

1. What operation modes does this push button support?
It has two modes: momentary (self-reset) and maintained (latching) for selection.

2. What is the contact configuration and contact material?
It uses 1NO+1NC contact combination, and the contact is made of silver for stable conduction.

3. What materials are used for the switch body?
The bezel and outer shell are all made of plastic with lightweight structure.

4. Does it have indicator light and optional colors?
Yes, it is illuminated type. Optional LED colors include Black, Blue, Green, Red, White and Yellow.

5. What are the main electrical parameters?
AC: 380V/220V 4.5A; DC: 220V/110V 0.6A, insulation voltage 660V, impulse voltage 2.5kV.

6. Does this button have waterproof performance?
Yes, it is designed with waterproof function for humid working environments.

7. What standards does the product comply with and where to use?
It meets CE, IEC and GB standards, mainly used for industrial control panels and automation equipment.

The post 22mm Push Button Illuminated Flat 1NO1NC Waterproof Momentary/Maintained appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting aperture, compatible with most industrial control panels and cabinets
• Pure momentary operation mode, automatic reset after release for jog and signal control
• Full plastic structure including bezel, head and shell, lightweight and cost-effective
• Flat head design, comfortable touch and neat appearance for panel assembly
• Built-in illuminated indicator, optional Red and Green LED colors for status distinction
• Standard 1NO+1NC contact configuration, widely used for various control circuits
• Complete electrical parameters, stable performance for AC and DC working circuits
• Compliant with GB/T14048.5, EN/IEC60947-5-1 international and national standards
• Low failure rate, long service life for long-term continuous industrial operation
• Simple installation and wiring, no complicated assembly required
• Universal design for mechanical equipment and electrical control systems

Technical Specifications

Product Attributes

• Mounting Dimension: 22mm
• Operation Type: Momentary / Self-reset
• Head Style: Flat
• Body Material: Plastic (Bezel, Head, Shell)
• Default Head Color: Green
• LED Color: Green, Red
• Contact: 1NO + 1NC
• Insulation Voltage: 600V
• Impulse Voltage: 2.5kV
• Thermal Current: 10A
• AC Parameter: 240V / 3A
• DC Parameter: 250V / 0.27A

Product Advantages

This 22mm flat momentary push button adopts full plastic construction, which is lightweight, economical and easy to install. It only supports momentary self-reset operation, which is specially designed for jogging, instantaneous start and signal triggering work. Equipped with 1NO+1NC universal contacts and dual-color LED indicators (red and green), it can clearly display equipment operating status. The product has complete electrical performance and strictly complies with GB and IEC electrical standards, ensuring safe and stable operation in AC and DC circuits. With simple structure, sensitive operation and low failure rate, it is a practical and cost-effective control component for various industrial electrical equipment.

Applications

• Industrial control cabinet instantaneous start, stop and jog control buttons
• Automation machinery equipment operation panel signal trigger switch
• Production line equipment temporary operation and manual control components
• Electrical box and distribution cabinet auxiliary signal control switch
• General electromechanical device momentary operation and status indication button

FAQ

1. What operation mode does this push button adopt?
It is a pure momentary self-reset type, which will automatically rebound after being pressed and released.

2. What materials are used for the whole switch?
The bezel, button head and outer shell are all made of high-quality plastic.

3. What contact configuration does it have?
It adopts classic 1NO+1NC (1 normally open + 1 normally closed) contact combination.

4. Does it have indicator light and optional colors?
Yes, it is an illuminated model. Optional LED colors are green and red.

5. What are the core electrical parameters?
Ui 600V, Uimp 2.5kV, Ith 10A; AC 240V/3A, DC 250V/0.27A.

6. What standards does the product comply with?
It complies with GB/T14048.5 and EN/IEC60947-5-1 electrical safety standards.

7. What are the main application scenarios?
It is widely used for instantaneous control and signal indication of industrial control cabinets, automation equipment and electromechanical devices.

The post 22MM Illuminated Flat Button Switch Momentary Plastic Push Button with 1NO1NC Contacts appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting size, widely compatible with industrial control panels and equipment panels
• Dual operation modes: maintained (latching) and momentary (self-reset) for diverse control needs
• Flame-retardant shell material, high safety for long-term power circuit application
• Excellent waterproof performance, works stably in humid working environments
• Flat head design with classic black appearance, simple and practical for panel assembly
• Fully illuminated with multi-color LED: Blue, Green, Red, White, Yellow optional
• 1NO+1NC contact configuration, universal design for most power control circuits
• Silver contact and silver pin, low resistance and stable electrical transmission
• Welding connection type, firm wiring and strong vibration resistance
• Rugged overall structure, long service life and low failure rate
• Professional power start switch for industrial and commercial equipment

Technical Specifications

Product Attributes

• Mounting Dimension: 16mm
• Operation Type: Maintained & Momentary
• Shell: Flame-retardant Material
• Head Style: Flat, Black
• Function: Waterproof & Illuminated
• LED Color: Blue / Green / Red / White / Yellow
• Contact: 1NO + 1NC
• Contact Material: Silver
• Pin Material: Silver
• Terminal: Welding Connection

Product Advantages

This 16mm illuminated push button adopts flame-retardant shell, which greatly improves safety for power control circuits. It supports both maintained and momentary operation to meet different control logic. Equipped with five optional LED colors, it can clearly distinguish equipment operating status. Both contacts and pins are made of silver to ensure stable conduction. The welding terminal makes wiring firm and not easy to fall off. With reliable waterproof capability, the switch can adapt to humid workshops and field equipment. Standard 1NO+1NC contacts and 16mm universal installation size make it highly compatible. It is a safe and durable choice for equipment power start and industrial control systems.

Applications

• Industrial equipment main power start and stop control panel
• Automation machinery maintained and jog dual-purpose control switch
• Electrical cabinet and distribution box waterproof circuit control components
• Commercial equipment multi-status indication and power switch
• General electromechanical device flame-retardant power start button

FAQ

1. What operation modes does this push button support?
It has two optional modes: maintained (latching) and momentary (self-reset).

2. What is the shell characteristic and head style?
The shell is made of flame-retardant material, with flat design and black head color.

3. How many LED colors are available for selection?
Five colors: Blue, Green, Red, White and Yellow for different status marking.

4. What is the contact configuration and material?
It uses 1NO+1NC contact form, and both contact and pin are made of silver.

5. What kind of connection terminal does it use?
It adopts welding connection, which is firm and suitable for long-term use.

6. Does this button have waterproof and flame-retardant functions?
Yes, it features waterproof performance and flame-retardant shell for higher safety.

7. What are the main application scenarios?
Mainly used for power start, circuit control and status indication of various industrial and mechanical equipment.

The post 16mm Illuminated Push Button Multi-Color LED Maintained/Momentary Waterproof Power Start Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 10mm assembly hole, 14.8mm threaded design for easy panel installation
• Dual operation modes: latching and reset for flexible circuit control
• Normal open (NO) contact configuration, widely applied in general control circuits
• Two optional colors: green and red for status distinction
• Rated 1.5A current and 250VAC voltage for conventional AC circuits
• Wide working temperature: -28℃ ~ +85℃, adapt to diverse ambient conditions
• Long electrical lifespan up to 10,000 cycles for continuous use
• High insulation resistance ≥50MΩ to ensure electrical safety
• Strong dielectric strength: withstand 250VAC for 1 minute without breakdown
• Low contact resistance ≤500mΩ for stable signal transmission
• Compact threaded structure, small size and space-saving
• Rugged construction, ideal for industrial automation and machinery equipment

Technical Specifications

Product Attributes

• Model: DS-451B / DS-450B
• Mounting Aperture: 10mm
• Thread Specification: 14.8mm
• Operation: Latching & Reset
• Contact Type: Normal Open
• Color: Green / Red
• Rating: 250VAC, 1.5A
• Temperature Range: -28℃ ~ +85℃
• Electric Life: 10000 Cycles
• Insulation Resistance: ≥50MΩ
• Dielectric Strength: 250VAC/1min
• Contact Resistance: ≤500mΩ

Product Advantages

The DS-451B/450B push button switch features a 10mm standard mounting hole and 14.8mm threaded structure, enabling quick and firm installation on various control panels. It integrates latching and reset functions with normal open contacts, meeting the operation demands of most industrial control circuits. Available in green and red colors, it is convenient for equipment status identification. With rated parameters of 250VAC and 1.5A, it works stably in common AC circuits. The switch can operate normally within -28℃ to +85℃, adapting to cold and hot working environments. Excellent electrical performance including high insulation resistance, strong dielectric strength and low contact resistance guarantees operational safety and stability. The 10,000-cycle electrical lifespan ensures long-term service, making it a cost-effective component for industrial machinery.

Applications

• Industrial automation equipment control panel start-stop buttons
• General mechanical equipment latching and reset control switches
• Small electrical devices and instrument panel operation components
• Production line auxiliary equipment signal control buttons
• DIY electrical projects and mini machinery circuit control units

FAQ

1. What are the model and mounting size of this push button?
The models are DS-451B and DS-450B, with a standard 10mm assembly hole and 14.8mm thread.

2. What operation modes and contact type does it have?
It supports latching and reset dual modes, and adopts normal open (NO) contact design.

3. What color options are available?
Two classic colors for selection: green and red.

4. What are the rated electrical parameters?
Rated voltage is 250VAC and rated current is 1.5A.

5. What is the working temperature range?
It can work stably from -28℃ to +85℃.

6. What about electrical performance and service life?
Electric life reaches 10,000 cycles; insulation resistance ≥50MΩ, withstand 250VAC for 1 minute, contact resistance ≤500mΩ.

7. What are the main application scenarios?
Mainly used for industrial automation systems and various mechanical control equipment.

The post Ds-451b/450b Latching and Reset Normal Open Push Button Switch Assemble Hole 10mm In Green and Red appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Professional two-hand start design for punch press safety protection, compliant with ISO 13849-1 PLd safety standard
• Standard size: 30mm panel cut out, 72-75mm outer protective diameter, 65mm cover diameter, 22mm gland entry
• High-strength stainless steel housing with IP67 waterproof grade for harsh workshop environments
• Anti-vibration locking structure, stable installation and not easy to loose during equipment operation
• 2NO2NC (2 Normally Open + 2 Normally Closed) contact combination for safety control circuits
• Silver plated gold contact material, excellent conductivity, anti-oxidation and long service life
• Reset operation mode, standard green button color for unified equipment identification
• Equipped with 2m long shielded cable, plug-and-play design for easy wiring and installation
• Passed CE, UL, RoHS global certifications, reliable quality for worldwide industrial use
• Rugged industrial grade construction, durable for long-term heavy-duty operation
• Specially optimized for stamping, forming and other heavy mechanical equipment

Technical Specifications

Product Attributes

• Model: AR30B2R-22G
• Installation Size: 30mm Panel Cut Out
• Outer Diameter: 72-75mm
• Cover Size: 65mm
• Cable Entry: 22mm
• Housing: Stainless Steel
• IP Grade: IP67
• Operation Type: Reset
• Contact: 2NO2NC
• Contact Material: Silver Plated Gold
• Color: Green
• Cable: 2m Shielded Cable
• Feature: Anti-vibration Locking
• Standard: ISO 13849-1 PLd
• Certificates: CE, UL, RoHS

Product Advantages

This AR30B2R-22G two-hand start button is a dedicated safety component for punch presses. It strictly follows ISO 13849-1 PLd safety standard to effectively protect operators. The stainless steel shell with IP67 waterproof performance adapts to oil mist, dust and humid workshop conditions. Equipped with anti-vibration locking structure, it keeps firm installation during long-term machine operation. The silver-plated gold contacts ensure stable electrical conduction, and the 2NO2NC configuration meets the safety circuit design requirements of heavy machinery. The 2-meter shielded cable supports plug-and-play, simplifying on-site wiring. With CE, UL and RoHS multiple certifications, the product has stable quality and wide applicability. The unified green appearance and standard dimensions make it easy to match various 72mm outer diameter punch press equipment.

Applications

• Metal stamping punch press two-hand safety start control system
• Automotive mold processing equipment operating button assembly
• Heavy-duty metal forming machinery safety control components
• Industrial hydraulic press and mechanical press start switch
• Large workshop heavy machinery safety protection control panel

FAQ

1. What are the installation dimensions of this two-hand button?
Panel cut out is 30mm, outer protector diameter 72-75mm, cover diameter 65mm, with 22mm gland entry.

2. What is the material and waterproof level?
It adopts stainless steel housing and reaches IP67 waterproof grade.

3. What is the contact configuration and contact material?
2NO2NC contact form, and the contact is made of silver plated gold.

4. What operation mode and color does it use?
It is reset type and the standard button color is green.

5. What about the cable and installation?
Comes with 2m shielded cable, plug-and-play design for easy installation.

6. What safety standards and certifications does it have?
Compliant with ISO 13849-1 PLd, and certified by CE, UL, RoHS.

7. What are the main application scenarios?
Mainly used for 72mm outer diameter punch press, metal stamping equipment, automotive dies and heavy forming machines.

The post Two-hand start button switch for 72 outer diameter punch press AR30B2R-22G appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• 72mm large head design, specially customized for industrial punch press equipment
• Standard installation size: 30mm panel cut out, outer diameter 72-75mm, cover diameter 65mm
• Bright red mushroom head, high visibility for quick identification and operation in workshops
• Quick momentary action, realize immediate machine shutdown in emergency situations
• Reset operation mode, easy to restore normal working state after troubleshooting
• Silver plated gold contact, good electrical conductivity, anti-oxidation and long service life
• Multiple contact configurations: 1NO1NC, 2NC, 3NC to match diverse safety circuits
• Heavy-duty rugged construction, stable performance under high-stress working conditions
• Strictly compliant with international industrial safety standards for operator protection
• Simple installation and maintenance, suitable for long-term continuous use in manufacturing plants
• Perfect for metalworking, stamping machinery and various industrial production equipment

Technical Specifications

Product Attributes

• Model: AH30-V10092 / V1R110092
• Mounting Hole: 30mm
• Outer Diameter: 72-75mm
• Cover Size: 65mm
• Head Type: Large Mushroom Head
• Color: Red
• Operation: Reset Type
• Contact Material: Silver Plated Gold
• Contact Form: 1NO1NC / 2NC / 3NC
• Feature: Quick Emergency Shutdown

Product Advantages

This 72mm large head emergency stop button is professionally designed for punch presses and metalworking equipment. The red mushroom head is eye-catching in complex workshop environments, enabling operators to find and trigger it instantly during emergencies. It adopts reset operation and multiple contact combinations to adapt to different safety circuit designs. The silver-plated gold contacts ensure stable and reliable electrical connection without poor contact caused by long-term use. With standard installation dimensions, it is highly compatible with most 72mm series punch presses. The heavy-duty structure can withstand frequent operation and harsh industrial conditions, effectively protecting personnel and equipment safety. It is an essential safety component for stamping workshops and manufacturing production lines.

Applications

• Industrial punch press emergency stop safety control component
• Metal stamping and forming machinery emergency shutdown switch
• Metalworking production line safety protection button
• Large manufacturing equipment and workshop machinery emergency control panel
• Automotive parts processing press and heavy industrial mechanical equipment

FAQ

1. What are the installation dimensions of this emergency stop button?
The panel cut out is 30mm, outer protector diameter is 72-75mm and cover diameter is 65mm.

2. What is the appearance and operation mode?
It adopts large red mushroom head design and supports reset operation mode.

3. What material are the contacts made of?
The contacts are made of silver plated gold for stable conduction and oxidation resistance.

4. How many contact configurations are available?
Three optional types: 1NO1NC, 2NC and 3NC for different circuit requirements.

5. What is the core function of this switch?
It is used for emergency shutdown to cut off machine operation rapidly in accidents.

6. What kind of equipment is it suitable for?
It is specially designed for 72mm large head punch presses and related metalworking machinery.

7. Why choose mushroom head emergency stop button?
The red mushroom head has high visibility and sensitive response, which ensures quick operation in emergency scenarios.

The post 72mm Emergency stop button switch for the large head of the punch press AH30-V10092 V1R110092 appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm panel cut out, universal size for most industrial control panels and cabinets
• Flat head design with momentary (reset) operation, rebound automatically after release
• Silver plated gold contact, excellent electrical conductivity, anti-oxidation and long service life
• Diversified contact configurations: 1NO, 1NC, 1NO1NC, 2NO, 2NO2NC for various circuits
• Six optional colors: Green, Red, Yellow, Blue, Black, White for status classification
• Belongs to FUJI AR22 series, expandable with self-locking and LED illuminated versions
• LED indicator supports DC24V and AC220V dual voltage for clear working status display
• Industrial grade structure, stable performance in harsh workshop environments
• Easy installation and wiring, low maintenance for long-term continuous operation
• Complete series models for one-stop matching of industrial control systems

Technical Specifications

Product Attributes

• Mounting Dimension: 22mm
• Head Style: Flat Head
• Operation Type: Momentary / Reset
• Contact Material: Silver Plated Gold
• Contact Form: 1NO / 1NC / 1NO1NC / 2NO / 2NO2NC
• Available Color: Green, Red, Yellow, Blue, Black, White
• Extended Function: Self-locking, LED Light (DC24V/AC220V)
• Product Series: FUJI AR22 Industrial Push Button

Product Advantages

This FUJI AR22 series flat-head momentary push button adopts a universal 22mm installation size, which is highly compatible with mainstream industrial control equipment. The silver-plated gold contacts ensure stable conduction and effectively avoid poor contact caused by long-term use. Multiple contact types and rich color options can meet the differentiation needs of different circuit designs and equipment functions. The product is available in self-locking and LED illuminated versions with DC24V and AC220V voltage options for the indicator light, realizing flexible configuration. As an industrial-grade switch, it has solid structure, strong environmental adaptability, simple installation and low failure rate, which is a cost-effective control component for mechanical equipment and automation systems.

Applications

• Industrial machine tools and processing equipment start & signal control buttons
• Elevator operation panel and auxiliary control system components
• Power distribution cabinets and electrical box circuit control switches
• Building automation and intelligent control system operating buttons
• General industrial machinery and production line momentary control devices

FAQ

1. What is the installation size and operation mode of this push button?
The panel cut out is 22mm, and it adopts momentary reset operation, which rebounds automatically after being pressed.

2. What material are the contacts made of?
The contacts are made of silver plated gold, featuring good conductivity and oxidation resistance.

3. What contact configurations are available?
Optional types: 1NO, 1NC, 1NO1NC, 2NO, 2NO2NC to match different control circuits.

4. How many colors can I choose?
Six colors are available: Green, Red, Yellow, Blue, Black and White.

5. Are there optional extended functions for this series?
Yes, the series supports self-locking function and LED indicator with DC24V and AC220V voltage options.

6. What series does this product belong to?
It is a member of the FUJI AR22 industrial push button series with complete model specifications.

7. What are the main application scenarios?
Widely used for machine tools, elevators, distribution cabinets and building automation systems.

The post Flat-head reset start button switch AP/AR22FOR-11G10RYWS B appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting size, 5 pins design with latching operation mode
• Rectangle button head in classic yellow color, neat appearance and easy recognition
• Silver contact material, reliable conductivity and long service life
• IP40 protection grade for daily dust prevention in general working environments
• Wide working temperature: -25℃ ~ 55℃, adapt to conventional indoor & workshop conditions
• Multiple rated voltage options: 24V, 125V(110V), 250V(220V)
• Diversified current parameters for DC and AC circuits with different power factors
• Two lamp types optional: LED Lamp and Neon Lamp for different application demands
• Five lamp colors: Green, Red, Yellow, Blue, White for status differentiation
• Lamp supports full AC/DC voltage range: 6V, 12V, 24V, 110V, 220V
• Latching structure keeps stable state without repeated pressing
• Compact structure, easy installation and wide compatibility for various devices

Technical Specifications

Product Attributes

• Mounting Dimension: 16mm
• Pin: 5 Pins
• Operation Type: Latching
• Head: Rectangle, Yellow
• Contact: Silver
• IP Rating: IP40
• Temperature Range: -25℃ ~ 55℃
• Rated Current: 5A
• Main Voltage: 24V / 110V / 220V
• Lamp Style: LED / Neon
• Lamp Color: Green / Red / Yellow / Blue / White
• Lamp Voltage: 6V~220V AC/DC Universal

Product Advantages

This 16mm 5-pin latching push button adopts classic rectangular yellow head and silver contacts to ensure stable circuit conduction. It features IP40 dustproof performance and works reliably within -25℃ to 55℃. The product supports multiple voltage and current specifications, which can adapt to DC and AC circuits with different power factors. Users can choose LED or neon lamp as required, and the lamp supports full AC/DC voltage with rich color options for equipment status identification. The latching design maintains stable working state after operation, avoiding frequent operation. With standard 16mm installation and 5-pin terminal, it is easy to wire and install. Versatile parameters make it suitable for household appliances and various industrial equipment.

Applications

• Household appliances internal power control and function selection switches
• Electric power equipment and distribution auxiliary control components
• Industrial machine tools, textile machinery and printing equipment control panels
• Vessel and marine on-board electrical control switches
• Mining machinery and telecommunications equipment circuit control units

FAQ

1. What is the specification and operation mode of this push button?
It is 16mm mounting size with 5 pins, rectangle yellow head and latching operation mode.

2. What is the protection grade and working temperature?
IP40 dustproof grade, working temperature ranges from -25℃ to 55℃.

3. What are the main electrical parameters?
Rated current 5A, rated voltage includes 24V, 110V and 220V; it has detailed current values for DC and AC with different power factors.

4. What material are the contacts made of?
The contacts are made of silver for stable electrical connection.

5. What lamp types and colors are available?
Two lamp types: LED Lamp and Neon Lamp; optional colors are green, red, yellow, blue and white.

6. What voltage does the indicator lamp support?
The lamp is compatible with AC/DC 6V, 12V, 24V, 110V and 220V.

7. What equipment is this switch suitable for?
It is widely used in home appliances, power facilities, machine tools, ships, textile, printing, mining and telecommunications devices.

The post 12V 16mm 5 Pins Latching Yellow Rectangle Push Button Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting aperture, universal size for most control panels and equipment housings
• 5 pins terminal design with latching operation, keep status steadily after pressing
• Rectangle button shape, compact structure, space-saving for equipment assembly
• Silver contact material, excellent electrical conductivity and long service life
• IP40 protection grade, effective dustproof for ordinary indoor and workshop environments
• Wide temperature adaptability: -25℃ ~ 55℃ for daily and general industrial use
• Rated current up to 5A, compatible with multiple conventional power circuits
• Multiple working voltages: 24V, 125V(110V), 250V(220V) for diverse equipment
• Complete current parameters for DC and AC circuits with different power factors
• Dual lamp options: LED Lamp and Neon Lamp to meet different lighting demands
• Lamp supports full AC/DC voltage: 6V, 12V, 24V, 110V, 220V
• Five lamp colors: Green, Red, Yellow, Blue, White for status identification
• Widely applicable for household appliances and various industrial equipment

Technical Specifications

Product Attributes

• Mounting Dimension: 16mm
• Terminal: 5 Pins
• Operation Type: Latching
• Head Style: Rectangle
• Contact: Silver
• IP Rating: IP40 Dustproof
• Temperature Range: -25℃ ~ 55℃
• Rated Current: 5A
• Working Voltage: 24V / 110V / 220V
• Lamp Style: LED / Neon Lamp
• Lamp Color: Green / Red / Yellow / Blue / White
• Lamp Voltage: AC/DC 6V~220V Universal

Product Advantages

This 16mm 5-pin latching rectangle push button adopts silver contacts to ensure stable and durable electrical connection. With IP40 dustproof capability and -25℃ to 55℃ working temperature range, it adapts to most indoor and ordinary industrial environments. The product is equipped with complete electrical parameters, supporting multiple voltage levels and matching DC & AC circuits with different power factors. Users can freely choose LED or neon lamp, and the indicator lamp covers full AC/DC voltage with rich color options for clear equipment status display. The latching structure keeps the switch state without repeated operation. Standard 16mm size and 5-pin terminals make wiring and installation simple. It is a versatile control component for household appliances and multiple industrial fields.

Applications

• All kinds of household appliances power switch and function selection components
• Electric power facilities and power distribution equipment control buttons
• Industrial machine tools, textile machinery and printing equipment control panels
• On-board electrical control switches for vessels and marine equipment
• Mining machinery and telecommunications equipment circuit control units

FAQ

1. What is the basic specification and operation mode of this push button?
It is 16mm mounting size with 5 pins, rectangle head and latching operation mode.

2. What is the protection grade and working temperature?
It reaches IP40 dustproof grade, and the operating temperature is from -25℃ to 55℃.

3. What are the main electrical parameters?
Rated current is 5A; working voltage includes 24V, 110V and 220V. It has detailed current data for DC and AC with different power factors.

4. What material are the contacts made of?
The contacts are made of high-quality silver for stable conduction.

5. What lamp types and colors are optional?
LED lamp and neon lamp are available; optional colors are green, red, yellow, blue and white.

6. What voltage does the indicator lamp support?
The lamp is compatible with AC/DC 6V, 12V, 24V, 110V and 220V.

7. What equipment is this switch suitable for?
It is widely used in home appliances, electric power, machine tools, vessels, textile, printing, mining and telecommunications equipment.

The post 16mm 5 Pins Latching Rectangle Push Button Switch 12V appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• IECEx and ATEX dual explosion-proof certifications, complies with IEC60079 & EN60079 standards
• Professional explosion-proof design, suitable for Zone 1, 2, 21, 22 hazardous environments
• High-quality polyamide plastic housing, corrosion resistance and anti-ignition performance
• IP66 full protection, effectively resist dust, water, grease and moisture ingress
• Wide ambient temperature range: -40℃ to 50℃ for severe working conditions
• Stable electrical parameters: AC 250V/16A, DC 110V/1A for industrial circuits
• Two contact material options: pure silver and gold-plated silver for selection
• Diversified contact combinations: 2NO, 2NC, 4NO, 4NC, mixed contacts for diverse circuits
• Two installation types: front rail mounting and board back mounting for flexible layout
• Front rail type fits TS35 standard rail or bolt fixation, panel type for 1-6mm board
• Long mechanical life up to 1 million times, durable for long-term continuous operation
• 2×2.5mm² standard terminals, reliable wiring connection
• No LED and non-smart design, simple structure and low failure rate
• Support OEM & ODM customization, single box contains 2 pieces
• CE 0575 certification, complete explosion-proof marks for global use

Technical Specifications

Product Attributes

• Certification: IECEx, ATEX, CE 0575
• Material: Polyamide Plastic
• IP Rating: IP66
• Temperature Range: -40℃ ~ 50℃
• Electrical Parameter: AC250V/16A, DC110V/1A
• Contact: Silver / Gold-plated Silver, Multiple Combinations
• Terminal: 2×2.5mm²
• Mechanical Life: 1,000,000 Cycles
• Light & Smart: Non-illuminated, Non-smart
• Installation: TS35 Rail / 1-6mm Panel
• Applicable Zone: Zone1/2/21/22 Hazardous Area
• Custom: Support OEM & ODM

Product Advantages

This explosion-proof push button is certified by IECEx and ATEX, fully complying with international explosion-proof standards, which ensures safe operation in explosive gas and dust environments. It adopts high-performance polyamide material, featuring excellent corrosion resistance and anti-ignition capability. IP66 high protection grade effectively blocks water, dust and grease, adapting to harsh industrial conditions. The product has complete electrical specifications and two optional contact materials, with various contact combinations to match different control circuits. It supports two mainstream installation methods, compatible with standard TS35 guide rails and common panels, bringing great flexibility for on-site construction. With 1 million mechanical service life, the switch has stable performance and low maintenance cost. It does not have complex smart and light components, so the failure rate is extremely low. Meanwhile, OEM and ODM services are available to meet personalized demands for different industrial projects.

Applications

• Chemical industry production workshops with flammable and explosive gas
• Oil, natural gas exploitation, transportation and storage equipment control panels
• Pharmaceutical manufacturing plants with explosive dust and volatile materials
• Zone 1, 2, 21, 22 hazardous area automation control systems
• Mining, paint, coating and other industries with flammable dust environments
• Explosion-proof electrical cabinets and increased safety enclosures (IP54 and above)

Certification	EX mark
IECEx	Ex de IIC T6 GB  Ex tb IIIC T 80°C Db
ATEX	II 2GD, Ex de IIC T6 Gb  Ex tb IIIC T 80°C Db

Descriptions:
The standard diameter of front operation head of board front mounting rail type, board back type is 30mm, which is mounted on the board of I up to 6mm. The explosion—proof component of board front type is mounted on the standard rail of 35mm or fixed by bolt. The explosion—proof component of board back type are connected to the pre—mounted front operation head part with a clamp. The component of board front mounting rail type and board back type are attached by the terminals. The explosion—proof component of board front mounting rail type and board back type shall be mounted in the enclosure of increased safety “e” which the protection degree is up to IP54.

The various kinds of type of explosion—proof button components and explosion—proof switch components can be combined when the different operation heads are equipped with the explosion—proof switch module of board front mounting rail type and board back type.

Order specifications:

Outline dimensions:

Board front mounting rail type mounting: May be held on mounting rails TS35*7.5 or with screws

Board back type mounting:On 1-6mm panel

FAQ

1. What explosion-proof certifications does this button have?
It has IECEx and ATEX dual certifications, also passes CE 0575, and complies with IEC60079 and EN60079 standards.

2. What is the protection grade and working temperature?
The protection grade is IP66; the applicable ambient temperature ranges from -40℃ to 50℃.

3. What are the rated electrical parameters?
Rated AC 250V/16A, rated DC 110V/1A, and the terminal specification is 2×2.5mm².

4. What contact materials and combinations are available?
Contact materials are silver and gold-plated silver; multiple combinations such as 2NO, 2NC, 4NO and mixed contacts are optional.

5. What installation ways does it support?
Two types: front rail mounting (fit TS35 standard rail) and board back mounting (fit 1-6mm panel).

6. Does it have LED light and smart function? What is the service life?
It is non-illuminated and non-smart type; the mechanical life can reach 1 million times.

7. Which hazardous areas and industries is it suitable for?
Designed for Zone 1, 2, 21, 22, widely used in chemical, oil & gas, pharmaceutical and other flammable environments.

8. Does it support customization and what is the packing standard?
OEM and ODM are supported; standard package is 2 pieces per box.

The post IECEx and ATEX Certified Plastic Explosion-proof Push Button Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.
