• Dual mounting sizes: 19mm and 22mm, compatible with most professional equipment and control panels
• Adopt advanced capacitive touch technology, sensitive response and stable sensing performance
• Full stainless steel bezel and shell, wear-resistant, anti-corrosion and long service life
• IP67 waterproof grade, effectively block water and dust for indoor and outdoor use
• Flat head design, concise appearance and compact structure, saving installation space
• Dual connection solutions: pre-attached cable and welding terminal for flexible assembly
• NO (Normally Open) contact configuration, suitable for conventional signal triggering circuits
• Diverse lamp options: illuminated and non-illuminated modes for different usage needs
• Multiple lamp types: ring lamp, ring+power lamp and other optional styles
• Rich LED colors: red, green and dual-color to distinguish equipment operating status
• Integrated pre-wired structure, no extra wiring work, easy and fast installation
• Industrial-grade workmanship, sturdy construction, low failure rate for long-term operation
• Wide application range for professional machinery, automation and general electrical devices

Technical Specifications

Product Attributes

• Mounting Dimension: 19mm / 22mm Dual Options
• Working Mode: Capacitive Touch
• Head Style: Flat Head
• Material: Full Stainless Steel
• IP Rating: IP67 Waterproof
• Contact Type: NO
• Connection: Pre-wired / Welding
• Lamp: Illuminated / Non-Illuminated
• Lamp Style: Ring, Ring+Power
• LED Color: Red, Green, Dual Color

Product Advantages

This 19/22mm capacitive touch sensor switch adopts premium stainless steel for both bezel and shell, which delivers excellent anti-rust, anti-corrosion and wear resistance. Supported by mature capacitive touch technology, the switch reacts sensitively and operates stably. With IP67 waterproof performance, it can work normally in dusty and slightly wet environments. Two mainstream mounting sizes (19mm and 22mm) ensure high compatibility with various professional equipment and control panels. It comes with pre-wired cable for plug-and-play installation, and also reserves welding terminals to meet different assembly requirements. The flat head design is simple and compact. Multiple lamp types and LED color choices help users clearly identify equipment status. Adopting standard NO contact, it fits most conventional signal control circuits. With reliable quality and easy maintenance, this switch is a cost-effective choice for industrial automation, professional machinery and outdoor electrical facilities.

Applications

• Industrial automation equipment touch control panels and signal sensors
• Professional mechanical equipment operation buttons and status indicator switches
• Indoor electrical cabinets and low-voltage control system components
• Slightly wet outdoor devices and field waterproof touch modules
• Instrumentation and testing equipment touch trigger switches
• Commercial intelligent devices and public access control touch buttons

FAQ

1. What mounting sizes are available for this touch switch?
Two standard sizes for selection: 19mm and 22mm.

2. What working principle and protection level does it have?
It uses capacitive touch technology, and the protection grade is IP67 with good waterproof and dustproof ability.

3. What are the main materials and head style?
The bezel and shell are all made of stainless steel, and it is designed with flat head.

4. What connection methods are supported?
It supports pre-wired and welding two connection ways for installation.

5. What is the contact configuration of the switch?
The contact type is NO (Normally Open), which is suitable for general signal circuits.

6. About the lamp and LED color options?
It has illuminated and non-illuminated modes; lamp types include ring lamp and ring+power lamp, available in red, green and dual color.

7. What are the core strengths of this product?
Stainless steel construction, IP67 waterproof, sensitive capacitive touch, easy installation and diverse configurations.

8. What main scenarios is this switch applied to?
Widely used for professional equipment, industrial automation, outdoor devices and various electrical control systems.

The post 19 22mm Stainless Steel Touch Sensor Switch with LED IP67 Waterproof Pre-wired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

The post Automotive Switch 20A 12VDC/10A 30VDC DPDT Rocker Switches Auto Power 5 Pin Auto Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting size, flat head design, latching operation mode for stable status keeping
• Made of high-quality SUS304 stainless steel, durable, corrosion-resistant and easy to clean
• IP68 waterproof & dustproof grade, IK69 level available, adapt to harsh wet and dusty environments
• Dot LED indicator, ring lamp optional, multiple LED colors and dual/tri-color lamp support
• Complete prewired design, 24AWG/26AWG wire, 150mm/300mm standard length, customized length acceptable
• Wide voltage range: 3-24V AC/DC, rich LED voltage options covering low voltage to mains voltage
• Low power consumption, working current below 20mA, energy-saving for long-term operation
• Moderate operating force 4-8N, comfortable touch experience, sensitive response
• Excellent electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength, guarantee circuit safety
• Diversified head styles: concave, flat, round, square and other shapes for selection
• Multiple shell sizes and surface treatments: aluminum oxide, multi-color anodized finish
• Rich contact configurations: NO, NC, 1NO1NC, 2NO2NC, 3NO3NC and prolonged pulse type
• Gold and silver dual contact materials, good conductivity and anti-oxidation
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃ for different ambient conditions
• Long service life: 1 million mechanical & electrical cycles, total lifespan up to 40000 hours
• Compliant with CE EN 60947-5-1:2017 standard, reliable quality for global use
• Support full customization on appearance, wiring, lamp and contact parameters

Technical Specifications

Product Attributes

• Mounting Size: 22mm Flat Type
• Operation Mode: Latching
• Body Material: SUS304 Stainless Steel
• IP Rating: IP68, Support IK69 Upgrade
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Rated Spec: 3-24V, ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Dot & Ring LED, Multi-color & Multi-voltage
• Head & Shell: Multiple Shapes, Sizes & Surface Treatments
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1:2017

Product Advantages

This 22mm flat piezo touch switch adopts premium SUS304 stainless steel, paired with IP68 high waterproof and dustproof performance, and optional IK69 anti-impact grade, which can work stably in various harsh environments. The latching design keeps the switch state steadily, and the 4-8N moderate operating force brings sensitive and comfortable touch experience. It is equipped with prewired harness with multiple wire gauges and lengths for easy installation, and also supports welding connection. The product has complete electrical parameters, gold and silver contacts ensure stable conduction and long service life, with 1 million mechanical & electrical cycles and 40000-hour total lifespan. It supports abundant customization including head style, shell size, anodized color, LED color and voltage, and contact modes. Complying with CE international standard, it has strong compatibility. The low power consumption design is suitable for long-term operation, and it can be combined with single-chip microcomputer to realize tapping trigger, music rhythm and lighting control functions, which is an ideal component for smart hardware and DIY development.

Applications

• Smart hardware development and electronic DIY project control components
• Impact sensor modules and programmable trigger sensing devices
• Music rhythm linkage and lighting system control switches
• Industrial control panels, outdoor equipment and waterproof touch buttons
• Automation equipment, medical devices and sanitary equipment touch switches
• Low-voltage electronic equipment and customized embedded control modules

FAQ

1. What is the installation size and operation mode of this piezo switch?
The standard mounting size is 22mm flat head, and it adopts latching operation mode.

2. What material and protection level does it have?
Main body is made of SUS304 stainless steel; standard IP68 grade, IK69 high protection level is optional.

3. What are the temperature range and operating force?
Two temperature options: -20°~55℃ and -40℃~+75℃; operating force is 4 to 8N.

4. What are the core electrical parameters?
Rated voltage 3-24V, working current below 20mA; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

5. What contact materials and configurations are available?
Contact materials: gold and silver; multiple configurations such as NO, NC, 1NO1NC, 2NO2NC and prolonged pulse.

6. About the wiring and LED configuration?
Support welding and prewired (24AWG/26AWG, 150/300mm customizable); dot/ring LED with multi-color and multi-voltage options.

7. What is the service life and applicable standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1:2017.

8. What main scenarios is this product suitable for?
Widely used for smart hardware, DIY projects, impact sensors, lighting, music control and industrial waterproof equipment.

The post Dot LED Stainless Steel Latching 22mm Flat Piezo Switch IP68 Touch Switch with Prewired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 30mm mounting size, alu anodized shell, sturdy and anti-corrosion for long-term use
• Latching operation mode, keep stable circuit state after triggering without repeated operation
• IP68 full waterproof & dustproof grade, IK69 anti-impact level optional for harsh environments
• Rated current 2A, wide voltage range 3-24V, compatible with most low-voltage circuits
• Dual wiring options: prewired (24AWG/26AWG) and traditional welding connection
• Standard wire length 150mm/300mm, customized wire length is available on demand
• Moderate operating force 4-8N, sensitive touch response and comfortable operation feel
• Gold and silver contact materials, excellent conductivity and oxidation resistance
• Outstanding electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength, ensure circuit operation safety
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃ for different working conditions
• Rich head styles: concave, flat, round, square and other multi-style options
• Ring LED design, available in single color, dual color and tri-color lamp solutions
• Complete LED voltage specifications covering AC and DC low voltage to mains voltage
• Diversified contact configurations: NO, NC, 1NO1NC, 2NO2NC, 3NO3NC and pulse type
• Multiple shell lengths and anodized color options to meet personalized appearance demands
• Long service life: 1 million mechanical & electrical cycles, total lifespan up to 40000 hours
• Low power consumption and compact structure, ideal for DIY and embedded projects
• Compliant with CE EN 60947-5-1:2017 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 30mm
• Operation Mode: Latching
• Shell: Aluminum Anodized & SUS304
• IP Rating: IP68, Optional IK69
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Rated Spec: 3-24V, 2A / Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Ring LED, Multi-color & Multi-voltage
• Head & Shell: Multiple Shapes, Sizes & Anodized Colors
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1:2017

Product Advantages

This 30mm anodized aluminum piezo touch switch adopts high-quality anodized aluminum and SUS304 materials, featuring strong corrosion resistance and wear resistance. With IP68 waterproof and dustproof performance plus optional IK69 anti-impact capability, it can operate stably in damp, dusty and impact-prone harsh environments. The latching structure locks the switch state effectively. It is rated at 2A and compatible with 3-24V circuits, covering most low-voltage control systems. Equipped with prewired harness and reserved welding terminals, the wiring is flexible for different installation demands. Gold and silver contacts ensure stable conduction and long service life. The product has two temperature options and complete electrical indicators, with 1 million mechanical and electrical cycles and 40000-hour total lifespan. It supports rich customization on appearance, lights and contacts, and complies with CE international standards. With fast response and low power consumption, it can cooperate with single-chip microcomputers to realize impact sensing, music rhythm and lighting linkage functions, which is an excellent choice for smart hardware development, electronic DIY and industrial control equipment.

Applications

• Smart hardware development and electronic DIY circuit control modules
• Impact sensor and programmable tapping trigger sensing devices
• Music rhythm linkage, stage lighting and intelligent lighting control systems
• Industrial control panels, outdoor machinery and waterproof touch operation buttons
• Sanitary equipment, medical devices and public access control switches
• Low-voltage embedded equipment and customized electronic control components

FAQ

1. What is the installation size and operation type of this piezo switch?
The standard mounting hole is 30mm, and it adopts latching operation mode.

2. What protection levels does it support?
Standard IP68 waterproof and dustproof grade, and IK69 anti-impact level is available for upgrade.

3. What are the electrical specifications?
Rated voltage 3-24V, rated current 2A, working current below 20mA.

4. What temperature ranges and operating force does it have?
Two temperature ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. What contact materials and electrical performance parameters?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. What wiring methods and wire specifications?
Support welding and prewired connection; wire gauge 24AWG/26AWG, standard length 150mm/300mm, customizable.

7. About the lamp and customizable items?
It uses ring LED with abundant colors and voltage options; head shape, shell size, contact mode and anodized color can be customized.

8. What is the service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1:2017.

9. What are the main application scenarios?
Mainly used for smart hardware, DIY projects, sensors, lighting control and various industrial waterproof equipment.

The post IP68 Touch Switch with Prewired Rating 2A Alu Anodized Latching 30mm Piezo Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting size with square head design, elegant and easy to identify on control panels
• Momentary (self-reset) operation mode, ideal for jog control and temporary signal triggering
• High-quality SUS304 stainless steel head and body, anti-corrosion, sturdy and easy to clean
• IP68 full waterproof & dustproof grade, IK69 anti-impact level available for harsh environments
• Compliant with RoHS and CE EN 60947-5-1:2017 standards, meets global environmental & electrical norms
• Rated 2A current and 3-24V wide voltage range, compatible with most low-voltage circuits
• Dual wiring solutions: prewired (24AWG/26AWG) and traditional welding connection
• Standard wire length 150mm/300mm, customized wire length is supported for diverse installation
• Moderate 4-8N operating force, sensitive touch response and comfortable operation experience
• Dual working temperature ranges: -20℃~55℃ and -40℃~+75℃ for various ambient conditions
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation performance
• Outstanding electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to guarantee circuit safety
• Rich head styles: concave, flat, round, square and other shapes for selection
• Ring lamp design, available in single color, dual color and tri-color LED indicators
• Complete LED voltage specifications covering AC and DC from low voltage to mains voltage
• Diversified contact configurations: NO, NC, 1NO1NC, 2NO2NC, 3NO3NC & prolonged pulse type
• Multiple shell lengths and surface treatments (anodized, aluminum oxide) for personalized demands
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours lifespan
• Low power consumption and compact structure, perfect for microcontroller linked DIY projects

Technical Specifications

Product Attributes

• Mounting Dimension: 22mm Square Head
• Operation Mode: Momentary (Self-reset)
• Main Material: SUS304 Stainless Steel
• IP Rating: IP68, Optional IK69 Anti-impact
• Certification: RoHS, CE EN 60947-5-1:2017
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, 2A / Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Ring LED, Multi-color & Multi-voltage Optional
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, Total 40000 Hours

Product Advantages

This 22mm square head momentary piezo switch is made of premium SUS304 stainless steel, featuring excellent corrosion resistance and structural rigidity. It is equipped with IP68 waterproof/dustproof and optional IK69 anti-impact performance, working reliably in wet, dusty and collision-prone industrial and outdoor environments. Adopting momentary self-reset design, it is perfectly suitable for instantaneous signal triggering and jog control. With 2A rated current and 3-24V wide voltage compatibility, it adapts to most low-voltage control circuits. Dual wiring methods including prewired harness and welding terminals greatly improve installation flexibility. Gold and silver contacts ensure stable electrical conduction and long service life. The product supports a full set of customization on head shape, LED light, contact mode and shell size, and complies with RoHS and CE standards for global sales and projects. It has fast response, low power consumption and long service life, and can be matched with single-chip microcomputers to realize tapping trigger, music rhythm and lighting linkage functions, which is an ideal component for smart hardware development, electronic DIY and various industrial control devices.

Applications

• Smart hardware development and electronic DIY instantaneous control modules
• Impact sensor and programmable tapping trigger sensing equipment
• Stage lighting, music rhythm linkage and intelligent lighting control systems
• Industrial control panels, outdoor machinery and waterproof momentary operation buttons
• Sanitary equipment, medical devices and public access control touch switches
• Low-voltage embedded electronic equipment and customized circuit components

FAQ

1. What is the installation size and operation mode?
The mounting hole is 22mm with square head, and it adopts momentary (self-reset) operation mode.

2. What protection grades and certifications does it have?
It reaches IP68 waterproof & dustproof grade, IK69 anti-impact is optional; certified by RoHS and CE EN 60947-5-1:2017.

3. What are the core electrical parameters?
Rated voltage 3-24V, rated current 2A, working current below 20mA.

4. What temperature range and operating force?
Two options: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. What about contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. What wiring methods are available?
Support welding and prewired (24AWG/26AWG), standard wire length 150mm/300mm, customizable.

7. Can I customize lights, head styles and contacts?
Yes. It supports various head shapes, multi-color/multi-voltage ring LED, and diverse contact configurations.

8. What is the service life?
Mechanical and electrical life are both 1 million times, total service life up to 40000 hours.

9. What are the main application scenarios?
Mainly used for smart hardware, DIY projects, sensors, lighting control and industrial waterproof equipment.

The post Square Head Rating 2A Stainless Steel Momentary 22mm Piezo Switch IP68 Rohs Touch Switch with Prewired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 25mm mounting aperture, widely compatible with various industrial and intelligent control panels
• Latching operation mode, keep stable circuit status after triggering without repeated pressing
• High-quality SUS304 stainless steel structure, wear-resistant, anti-corrosion and easy to clean
• IP68 waterproof & dustproof grade, IK69 anti-impact level available for harsh working conditions
• Rated 2A current and 3-24V wide voltage range, suitable for most low-voltage control circuits
• Dual wiring design: prewired harness and traditional welding terminal for flexible installation
• 24AWG/26AWG wire with standard 150mm/300mm length, customized wire length is acceptable
• 4-8N moderate operating force, sensitive touch response and comfortable hand feel
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃ to adapt diverse ambient temperatures
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation ability
• Superior electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to ensure circuit safety
• Multiple head styles: concave, flat, round, square and other styles for selection
• Ring LED indicator, support single color, dual color and tri-color lighting effects
• Complete LED voltage specifications covering full AC and DC voltage range
• Diversified contact configurations: NO, NC, 1NO1NC, 2NO2NC, 3NO3NC and pulse type
• Multiple shell lengths and oxide/anodized colors (green, blue, red, yellow, silver, black)
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Low power consumption and compact structure, perfect for MCU linked DIY and sensor projects
• Compliant with CE EN 60947-5-1 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 25mm
• Operation Mode: Latching
• Main Material: SUS304 Stainless Steel
• Surface Finish: Oxide & Multi-color Anodized
• IP Rating: IP68, Optional IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, 2A / Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Custom Sizes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1:2017

Product Advantages

This 25mm latching piezo touch switch adopts premium SUS304 stainless steel, matched with various oxide and anodized colors for personalized appearance. With IP68 waterproof, dustproof and optional IK69 anti-impact performance, it runs stably in wet, dusty and collision-prone harsh environments. The latching structure keeps the circuit state locked after operation, which is suitable for long-term power-on control. It supports 3-24V wide voltage and 2A rated current, compatible with most low-voltage control systems. Dual wiring solutions of prewired harness and welding terminals meet different installation requirements. Gold and silver contacts ensure stable conduction and long service life. The product has two temperature ranges and complete electrical indicators, with 1 million mechanical & electrical cycles and 40000-hour total lifespan. It supports full customization on head shape, LED, contact and shell size, and complies with CE international standard. Featuring fast response and low power consumption, it can cooperate with single-chip microcomputers to realize tapping trigger, music rhythm and lighting linkage functions, which is an ideal component for smart hardware, electronic DIY and industrial control equipment.

Applications

• Smart hardware development and customized electronic DIY control modules
• Impact sensors and programmable tapping trigger sensing devices
• Stage lighting, music rhythm linkage and intelligent lighting control systems
• Industrial control panels, outdoor machinery and waterproof latching buttons
• Sanitary equipment, medical devices and public access control switches
• Low-voltage embedded equipment and special industrial control components

FAQ

1. What is the mounting size and operation mode?
The standard mounting hole is 25mm, and it adopts latching operation mode.

2. What protection levels and surface colors are available?
Standard IP68 waterproof & dustproof grade, IK69 anti-impact is optional; oxide green, blue, red, yellow, silver, black are available.

3. What are the core electrical parameters?
Rated voltage 3-24V, rated current 2A, working current below 20mA.

4. What temperature range and operating force?
Two options: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring methods and wire specifications?
Support welding and prewired (24AWG/26AWG), standard length 150mm/300mm, customizable.

7. What customizable parts does this switch have?
Head style, LED color & voltage, contact mode, shell length and surface color can be customized.

8. Service life and applicable standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1:2017.

9. Main application scenarios?
Widely used for smart hardware, DIY projects, sensors, lighting control and industrial waterproof equipment.

The post Rating 2A Stainless Steel Latching 25mm Piezo Switch IP68 Touch Switch with Prewired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 19mm mounting aperture, widely compatible with industrial panels and testing equipment housings
• Momentary (self-reset) operation mode, ideal for temporary triggering and signal collection work
• High-quality SUS304 stainless steel construction, anti-corrosion, sturdy and easy to clean
• IP68 full waterproof & dustproof grade, IK69 anti-impact level available for harsh workshop environments
• Rated voltage 3-24V, matched with 24V system specially, working current below 20mA for low power consumption
• Dual wiring solutions: prewired harness and traditional welding terminal for diverse installation demands
• 24AWG/26AWG wire specification, standard length 150mm/300mm, customized wire length is supported
• 4-8N moderate operating force, sensitive touch response and stable triggering performance
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to low temperature and high temperature working conditions
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation performance
• Superior electrical parameters: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength, effectively guarantee circuit operation safety
• Multiple head styles: concave, flat, round, square and customized shapes for selection
• Ring LED indicator design, available in single color, dual color and tri-color lighting modes
• Complete LED voltage specifications covering full AC and DC voltage range from low voltage to mains voltage
• Diversified contact configurations: NO, NC, 1NO1NC, 2NO2NC, 3NO3NC and prolonged pulse type
• Multiple shell lengths and surface treatments (oxide, anodized) for personalized appearance design
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours lifespan
• Compact structure and fast response, professional for industrial detection and control equipment
• Compliant with CE EN 60947-5-1:2017 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 19mm
• Operation Mode: Momentary (Self-reset)
• Main Material: SUS304 Stainless Steel
• IP Rating: IP68, Optional IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Rated Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1:2017

Product Advantages

This 19mm momentary piezo switch is specially matched for 24V systems and made of premium SUS304 stainless steel. It has IP68 waterproof and dustproof performance plus optional IK69 anti-impact capability, adapting to various complex industrial environments. The momentary self-reset design is suitable for instantaneous signal triggering and data collection. It supports prewired and welding two wiring methods, which is convenient for on-site construction. With two temperature ranges and excellent electrical indicators, the switch runs stably in cold and hot conditions. Gold and silver contacts ensure low resistance and stable conduction, extending the service life. A full set of customization is available for head shape, LED light, contact mode and shell size to meet personalized project needs. It features fast response, low power consumption and long service life, and complies with CE international standard. It is a professional supporting component for industrial automation equipment, ultrasonic probes, microfluidic pumps and pressure relay detection devices.

Applications

• Industrial automation equipment safety threshold detection and signal trigger components
• Ultrasonic imaging probe control and instantaneous signal acquisition switches
• Microfluidic pump start-stop and operation control modules
• Pressure relay and pressure detection equipment threshold control buttons
• Testing instruments and laboratory equipment momentary operation switches
• Low-voltage industrial control systems and special detection device accessories

FAQ

1. What is the installation size and operation mode of this piezo switch?
The standard mounting hole is 19mm, and it adopts momentary (self-reset) operation mode.

2. What protection levels does it have?
It comes with standard IP68 waterproof & dustproof grade, and IK69 anti-impact level can be customized.

3. What are the voltage and current parameters?
Rated voltage 3-24V (optimized for 24V systems), working current is below 20mA.

4. What temperature range and operating force?
Two temperature options: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. What wiring methods and wire specifications?
Support welding and prewired connection; wire gauge 24AWG/26AWG, standard length 150mm/300mm, customizable.

7. Can I customize appearance and internal configurations?
Yes, head style, ring LED (color & voltage), contact mode and shell size can be customized.

8. What is the service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1:2017.

9. What professional equipment is it suitable for?
Mainly used for industrial automation, ultrasonic imaging probes, microfluidic pumps and pressure relays.

The post 24V Stainless Steel Momentary 19mm Piezo Switch IP68 Touch Switch with Prewired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 30mm mounting hole, widely compatible with various industrial control panels and equipment housings
• Momentary NO (Normally Open) design, perfect for instantaneous signal output and circuit triggering
• Based on piezoelectric effect, convert mechanical energy into electrical energy with fast response speed
• High-quality SUS304 stainless steel body, sturdy, corrosion-resistant and easy to clean
• IP68 waterproof & dustproof grade, IK69 anti-impact level optional for harsh working environments
• Wide voltage range 3-24V, specially optimized for 24V power supply systems
• Low power consumption, working current below 20mA, suitable for long-term continuous operation
• Dual wiring modes: prewired harness and traditional welding terminal for flexible installation
• 24AWG/26AWG wire, standard length 150mm/300mm, customized wire length is available
• 4-8N moderate operating force, comfortable touch and stable triggering performance
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to cold and hot environments
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation
• Outstanding electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to ensure circuit safety
• Diversified head styles: concave, flat, round, square and other customized shapes
• Ring LED design, available in single color, dual color and tri-color indicators
• Full range of LED voltages covering AC and DC from low voltage to mains voltage
• Multiple contact configurations including NO, NC, 1NO1NC and pulse type
• Various shell lengths and surface treatments: oxide, multi-color anodized finish
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Compliant with CE EN 60947-5-1:2017 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 30mm
• Operation Mode: Momentary NO
• Working Principle: Piezoelectric Effect
• Main Material: SUS304 Stainless Steel
• IP Rating: IP68, Optional IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1:2017

Product Advantages

This durable 30mm momentary NO piezo switch adopts mature piezoelectric technology, which can efficiently convert mechanical pressure into electrical signals with ultra-fast response. It is made of SUS304 stainless steel, equipped with IP68 waterproof and dustproof performance, and IK69 anti-impact grade is optional, so it can work stably in various harsh industrial environments. Designed for 24V systems and compatible with 3-24V wide voltage, it has low operating current and energy-saving features. The product supports prewired and welding dual wiring methods, which is convenient for different installation scenarios. Gold and silver contacts ensure stable conduction and long service life. It has two temperature adaptation ranges and excellent electrical indicators, with 1 million mechanical and electrical cycles and 4000-hour total lifespan. Multiple custom options are provided for head shape, LED light, contact mode and shell specifications to meet personalized project requirements. Complying with CE international standards, it is a reliable choice for industrial signal triggering, testing equipment and automation control systems.

Applications

• Industrial automation equipment instantaneous signal trigger and circuit control components
• Electronic testing instruments and laboratory equipment momentary start switches
• Low-voltage industrial equipment and 24V system control buttons
• Outdoor machinery and wet workshop waterproof signal output devices
• Smart electronic products and mechanical sensing modules
• General industrial electrical equipment circuit activation units

FAQ

1. What is the installation size and operation type of this piezo switch?
The mounting hole is 30mm, and it is momentary normally open (NO) type.

2. What working principle and protection levels does it adopt?
It works based on piezoelectric effect; standard IP68 waterproof & dustproof, IK69 anti-impact is optional.

3. What are the core electrical parameters?
Rated voltage 3-24V (24V dedicated), working current below 20mA.

4. Temperature range and operating force?
Two ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring ways and wire specifications?
Support welding and prewired; 24AWG/26AWG wire, 150mm/300mm length, customizable.

7. What customizable parts are available?
Head style, ring LED (color & voltage), contact configuration and shell size can be customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1:2017.

9. What are the main application scenarios?
Mainly used for industrial automation, testing instruments, 24V equipment and waterproof control devices.

The post Durable 24V Stainless Steel Momentary NO 30mm Piezo Switch with IP68 Prewired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting hole size for standard panel installation
• Elegant flat round head design with black appearance
• IP65 dustproof and waterproof level for indoor and industrial environment
• Momentary reset operation type for instant control triggering
• 1NO1NC contact combination meets most conventional circuit needs
• Rated 3A current, 250V working voltage stable load
• Dual illuminated design: Ring LED and power logo indicator
• 5 pin plug-in terminal for quick and firm wiring
• Premium black anodized metal enclosure material
• Silver contact material, anti-oxidation and long service life
• Industrial grade performance suitable for automotive and industrial equipment
• Plug-in connection structure, easy installation and replacement

Technical Specifications

Product Attributes

• Connection: Plug in
• Head Type: Flat
• Head Color: Black
• Contact Material: Silver
• Lamp Type: Ring
• LED Color: Optional Other Colors
• Contact Operation: 1NO + 1NC
• Shell Material: Black Anodized

Product Advantages

This 16mm IP65 momentary push button adopts flat round head and black anodized metal design. It features IP65 waterproof and dustproof performance, rated 3A 250V stable load. Dual ring and power logo LED provide clear status indication. Built with 1NO1NC contact and 5-pin plug-in terminal for easy wiring. Industrial-grade quality is perfect for automotive devices and industrial control panel long-term stable operation.

Applications

• 16mm industrial panel IP65 ring power logo LED push button
• Automotive equipment 3A 250V momentary 1NO1NC control switch
• Indoor machinery black anodized metal 5-pin illuminated button
• Dustproof workshop flat round head LED indicator push button
• Instrument and electrical cabinet replacement momentary switch

FAQ

1. Mounting size?
Standard 16mm mounting hole diameter.

2. Protection grade?
IP65 dustproof and waterproof level.

3. Rated parameter?
3A current, 250V voltage rating.

4. Illuminated style?
Ring LED + power logo double illuminated design.

5. Material & terminal?
Black anodized shell; 5 pin plug-in terminal.

The post 16mm IP65 Momentary Push Button Switch – 3A/250V, 5-Pin LED Illuminated (1NO1NC) appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 30mm mounting aperture, widely compatible with mainstream control panels and equipment casings
• Unique segmented dimming function, ideal for lighting adjustment and brightness control systems
• Momentary operation mode, suitable for instantaneous triggering and dimming adjustment operations
• Dual high protection: IK69 anti-impact + IP68 waterproof & dustproof for harsh environments
• Premium material combination: SUS304 stainless steel + aluminum oxide, anti-rust, corrosion-proof, flame retardant & high temperature resistant
• Exquisite precision manufacturing, durable surface color, anti-collision and pressure resistance
• Rated voltage 3-24V, low working current below 20mA, energy-saving for long-time use
• Dual wiring solutions: prewired harness and traditional welding terminal for flexible installation
• 24AWG/26AWG wire, standard length 150mm/300mm, customized wire length available
• 4-8N moderate operating force, comfortable touch and stable triggering performance
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to cold and hot working conditions
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation ability
• Superior electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to guarantee circuit safety
• Rich head styles: concave, flat, round, square and other customized shapes
• Dot & Ring dual lamp types, single color, dual color and tri-color LED optional
• Full LED voltage range: 3V~220V AC/DC universal for diverse power systems
• Various contact configurations: NO, NC, 1NO1NC, 2NO2NC, prolonged pulse etc.
• Multiple shell lengths and surface crafts: anodized & oxide multi-color options
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Support full customization for appearance and internal parameters
• Compliant with CE EN 60947-5-1 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 30mm
• Core Function: Segmented Dimming
• Operation Mode: Momentary
• Main Material: SUS304 + Aluminum Oxide
• Protection: IK69 Anti-impact + IP68 Waterproof
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Dot / Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1

Product Advantages

This 30mm segmented dimming piezo switch is a professional component specially designed for brightness adjustment. It adopts SUS304 stainless steel and aluminum oxide materials, featuring flame retardant, high temperature resistance, rust and corrosion resistance. With IK69 anti-impact and IP68 waterproof dual protection, it can work stably in complex outdoor and industrial environments. The momentary operation mode matches the use logic of segmented dimming, which is convenient for stepless and segmented brightness adjustment. The product supports 3-24V wide voltage and ultra-low operating current, which is energy-saving for long-term operation. Two wiring methods of prewired and welding meet different installation requirements. Gold and silver contacts ensure stable electrical conduction and long service life. It has two temperature adaptation ranges and excellent electrical indicators. A full range of customizable options including head shape, lamp type, lamp color, contact mode and shell specifications are available to meet personalized project needs. With 1 million mechanical and electrical cycles and 40000-hour total lifespan, it is reliable and durable. Compliant with CE international standards, it is the ideal choice for smart lighting systems, industrial control panels and various waterproof electronic equipment.

Applications

• Smart lighting systems and segmented brightness adjustment control switches
• Commercial lighting, stage lighting dimming and triggering components
• Industrial control panels and anti-collision waterproof operation buttons
• Outdoor electronic equipment and wet environment control modules
• Custom electronic devices and equipment dimming control units
• Low-voltage electrical systems and intelligent terminal touch switches

FAQ

1. What is the installation size and core function of this switch?
The mounting hole is 30mm, and it is a momentary piezo switch with segmented dimming function.

2. What protection levels and main materials does it have?
It has IK69 anti-impact and IP68 waterproof grade; made of SUS304 stainless steel and aluminum oxide.

3. What are the voltage and current parameters?
Rated voltage 3-24V, working current is below 20mA with low power consumption.

4. What temperature range and operating force?
Two ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring methods and wire specifications?
Support welding and prewired (24AWG/26AWG), 150mm/300mm length, customizable.

7. What lamp types and customizable items are available?
Dot lamp and ring lamp are optional; head style, LED, contact and shell can be customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1.

9. What main scenarios is it suitable for?
Mainly used for smart lighting dimming, industrial control, outdoor waterproof equipment and electronic devices.

The post 30mm Segmented Dimming IK69 Stainless Steel Momentary Piezoelectric Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.
