• Standard 16mm mounting size, widely compatible with industrial control panels and equipment panels
• Dual operation modes: maintained (latching) and momentary (self-reset) for diverse control needs
• Flame-retardant shell material, high safety for long-term power circuit application
• Excellent waterproof performance, works stably in humid working environments
• Flat head design with classic black appearance, simple and practical for panel assembly
• Fully illuminated with multi-color LED: Blue, Green, Red, White, Yellow optional
• 1NO+1NC contact configuration, universal design for most power control circuits
• Silver contact and silver pin, low resistance and stable electrical transmission
• Welding connection type, firm wiring and strong vibration resistance
• Rugged overall structure, long service life and low failure rate
• Professional power start switch for industrial and commercial equipment

Technical Specifications

Product Attributes

• Mounting Dimension: 16mm
• Operation Type: Maintained & Momentary
• Shell: Flame-retardant Material
• Head Style: Flat, Black
• Function: Waterproof & Illuminated
• LED Color: Blue / Green / Red / White / Yellow
• Contact: 1NO + 1NC
• Contact Material: Silver
• Pin Material: Silver
• Terminal: Welding Connection

Product Advantages

This 16mm illuminated push button adopts flame-retardant shell, which greatly improves safety for power control circuits. It supports both maintained and momentary operation to meet different control logic. Equipped with five optional LED colors, it can clearly distinguish equipment operating status. Both contacts and pins are made of silver to ensure stable conduction. The welding terminal makes wiring firm and not easy to fall off. With reliable waterproof capability, the switch can adapt to humid workshops and field equipment. Standard 1NO+1NC contacts and 16mm universal installation size make it highly compatible. It is a safe and durable choice for equipment power start and industrial control systems.

Applications

• Industrial equipment main power start and stop control panel
• Automation machinery maintained and jog dual-purpose control switch
• Electrical cabinet and distribution box waterproof circuit control components
• Commercial equipment multi-status indication and power switch
• General electromechanical device flame-retardant power start button

FAQ

1. What operation modes does this push button support?
It has two optional modes: maintained (latching) and momentary (self-reset).

2. What is the shell characteristic and head style?
The shell is made of flame-retardant material, with flat design and black head color.

3. How many LED colors are available for selection?
Five colors: Blue, Green, Red, White and Yellow for different status marking.

4. What is the contact configuration and material?
It uses 1NO+1NC contact form, and both contact and pin are made of silver.

5. What kind of connection terminal does it use?
It adopts welding connection, which is firm and suitable for long-term use.

6. Does this button have waterproof and flame-retardant functions?
Yes, it features waterproof performance and flame-retardant shell for higher safety.

7. What are the main application scenarios?
Mainly used for power start, circuit control and status indication of various industrial and mechanical equipment.

The post 16mm Illuminated Push Button Multi-Color LED Maintained/Momentary Waterproof Power Start Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Three standard sizes: 16mm, 19mm, 22mm
• IP67 waterproof & dustproof protection
• Maintained (latching) and momentary operation optional
• Pre-wired design for plug-and-play installation
• Illuminated with multiple LED color options
• Flat & high round head styles optional
• NO / 1NO+1NC contact configurations
• Gold-plated pins & silver-plated contacts
• Perfect for automotive start & lift systems

Technical Specifications

Product Advantages

This 16/19/22mm waterproof metal push button switch is designed for automotive start, lift control and industrial equipment systems. IP67 waterproof rating ensures stable performance in humid, outdoor and harsh environments. Pre-wired structure allows fast and easy installation without soldering. It supports both maintained and momentary modes with flexible contact configurations. High-quality metal construction and gold/silver contacts ensure long service life and reliable electrical performance.

Applications

• Automotive engine start & vehicle modification
• Electric lift, window and door control systems
• Industrial control panels & machinery operation
• Marine, outdoor and damp environment equipment
• Automotive interior & custom control panels
• Small power equipment & DIY projects

FAQ

1. What sizes does this push button support?
It supports 16mm, 19mm and 22mm standard mounting sizes.

2. Is this switch waterproof?
Yes, it has IP67 high-level waterproof and dustproof protection.

3. Does it come pre-wired?
Yes, pre-wired design supports direct plug-and-play installation.

4. Does it support maintained and momentary modes?
Yes, both maintained (latching) and momentary operation are optional.

5. What is this switch mainly used for?
It is widely used for automotive start systems, lift controls and industrial equipment.

The post 16 19 22mm Waterproof Metal Push Button Switch Maintained or Momentary Pre-wired for Automotive Start and Lift Systems appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• 16mm standard mounting hole size
• Black oxide metal housing for anti-corrosion & stylish look
• IP67 waterproof & dustproof protection
• High current design for stable power control
• Maintained (latching) and momentary operation optional
• Custom engraving / symbol / text available
• Illuminated ring LED with multiple color options
• Flat head style for standard panel installation
• Silver-plated contacts for excellent conductivity
• Perfect for access control & security systems

Technical Specifications

Product Advantages

This 16mm black metal push button switch is specially designed for access control and security systems. It features IP67 waterproof performance and high current capability for reliable long-term use. The black oxide metal shell is anti-corrosion and durable. Custom engraving service supports personalized text, symbol and logo to meet different identification needs. It supports both maintained and momentary modes with LED illumination for clear status indication. High-quality structure ensures stable performance and long service life.

Applications

• Access control systems & door control panels
• Security equipment & interlock systems
• Industrial control & automation devices
• Custom control panels with engraved symbols
• Automotive & vehicle interior control
• Outdoor & damp environment security equipment

FAQ

1. What is the mounting size of this switch?
Standard 16mm mounting hole size for general control panels.

2. Is this switch waterproof?
Yes, it has IP67 high-level waterproof and dustproof protection.

3. Does it support custom engraving?
Yes, custom text, symbol and logo engraving are available.

4. Does it support maintained and momentary modes?
Yes, both maintained (latching) and momentary operation are optional.

5. What is this switch mainly used for?
It is widely used for access control, security systems and custom control panels.

The post 16mm Black Metal Push Button Waterproof High Current Maintained Momentary Switch Access Control Custom Engraving appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Dual mounting sizes: 19mm and 22mm, compatible with most professional equipment and control panels
• Adopt advanced capacitive touch technology, sensitive response and stable sensing performance
• Full stainless steel bezel and shell, wear-resistant, anti-corrosion and long service life
• IP67 waterproof grade, effectively block water and dust for indoor and outdoor use
• Flat head design, concise appearance and compact structure, saving installation space
• Dual connection solutions: pre-attached cable and welding terminal for flexible assembly
• NO (Normally Open) contact configuration, suitable for conventional signal triggering circuits
• Diverse lamp options: illuminated and non-illuminated modes for different usage needs
• Multiple lamp types: ring lamp, ring+power lamp and other optional styles
• Rich LED colors: red, green and dual-color to distinguish equipment operating status
• Integrated pre-wired structure, no extra wiring work, easy and fast installation
• Industrial-grade workmanship, sturdy construction, low failure rate for long-term operation
• Wide application range for professional machinery, automation and general electrical devices

Technical Specifications

Product Attributes

• Mounting Dimension: 19mm / 22mm Dual Options
• Working Mode: Capacitive Touch
• Head Style: Flat Head
• Material: Full Stainless Steel
• IP Rating: IP67 Waterproof
• Contact Type: NO
• Connection: Pre-wired / Welding
• Lamp: Illuminated / Non-Illuminated
• Lamp Style: Ring, Ring+Power
• LED Color: Red, Green, Dual Color

Product Advantages

This 19/22mm capacitive touch sensor switch adopts premium stainless steel for both bezel and shell, which delivers excellent anti-rust, anti-corrosion and wear resistance. Supported by mature capacitive touch technology, the switch reacts sensitively and operates stably. With IP67 waterproof performance, it can work normally in dusty and slightly wet environments. Two mainstream mounting sizes (19mm and 22mm) ensure high compatibility with various professional equipment and control panels. It comes with pre-wired cable for plug-and-play installation, and also reserves welding terminals to meet different assembly requirements. The flat head design is simple and compact. Multiple lamp types and LED color choices help users clearly identify equipment status. Adopting standard NO contact, it fits most conventional signal control circuits. With reliable quality and easy maintenance, this switch is a cost-effective choice for industrial automation, professional machinery and outdoor electrical facilities.

Applications

• Industrial automation equipment touch control panels and signal sensors
• Professional mechanical equipment operation buttons and status indicator switches
• Indoor electrical cabinets and low-voltage control system components
• Slightly wet outdoor devices and field waterproof touch modules
• Instrumentation and testing equipment touch trigger switches
• Commercial intelligent devices and public access control touch buttons

FAQ

1. What mounting sizes are available for this touch switch?
Two standard sizes for selection: 19mm and 22mm.

2. What working principle and protection level does it have?
It uses capacitive touch technology, and the protection grade is IP67 with good waterproof and dustproof ability.

3. What are the main materials and head style?
The bezel and shell are all made of stainless steel, and it is designed with flat head.

4. What connection methods are supported?
It supports pre-wired and welding two connection ways for installation.

5. What is the contact configuration of the switch?
The contact type is NO (Normally Open), which is suitable for general signal circuits.

6. About the lamp and LED color options?
It has illuminated and non-illuminated modes; lamp types include ring lamp and ring+power lamp, available in red, green and dual color.

7. What are the core strengths of this product?
Stainless steel construction, IP67 waterproof, sensitive capacitive touch, easy installation and diverse configurations.

8. What main scenarios is this switch applied to?
Widely used for professional equipment, industrial automation, outdoor devices and various electrical control systems.

The post 19 22mm Stainless Steel Touch Sensor Switch with LED IP67 Waterproof Pre-wired appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• 22mm standard mounting hole size
• 15A high current for heavy-duty power control
• IP67 waterproof & dustproof protection
• LED illuminated & non-illuminated versions optional
• Flat & high round head styles available
• Multiple LED colors: Red, Green, Blue, Yellow
• Large silver contacts for stable conductivity
• Gold-plated pins for low resistance & long life
• Sturdy metal housing: SUS304/316, aluminum oxide
• CE & ROHS certified quality

Product Advantages

This 22mm 15A high current metal push button switch is built for heavy-duty industrial power control. It supports 15A large current to drive high-power equipment safely. IP67 waterproof rating ensures stable performance in wet, outdoor and harsh environments. Large silver contacts and gold-plated pins provide excellent conductivity and long service life. LED illumination offers clear status indication. Multiple head styles and materials meet various installation needs.

Applications

• Industrial power start/stop control systems
• Heavy machinery & high-current equipment
• Automotive, marine & outdoor control panels
• Generator, inverter & power distribution devices
• CNC equipment & industrial automation systems
• Vehicle modification & engineering equipment

FAQ

1. What is the mounting size?
Standard 22mm mounting hole size.

2. What is the rated current?
15A high current for heavy-duty power control.

3. Is this switch IP67 waterproof?
Yes, it has IP67 waterproof and dustproof protection.

4. Does it support LED and non-illuminated versions?
Yes, both illuminated and non-illuminated are optional.

5. What material are the contacts?
Large silver contacts for high conductivity and stability.

The post 22mm high current metal push button swith with LED appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 30mm mounting aperture, widely compatible with mainstream control panels and equipment casings
• Unique segmented dimming function, ideal for lighting adjustment and brightness control systems
• Momentary operation mode, suitable for instantaneous triggering and dimming adjustment operations
• Dual high protection: IK69 anti-impact + IP68 waterproof & dustproof for harsh environments
• Premium material combination: SUS304 stainless steel + aluminum oxide, anti-rust, corrosion-proof, flame retardant & high temperature resistant
• Exquisite precision manufacturing, durable surface color, anti-collision and pressure resistance
• Rated voltage 3-24V, low working current below 20mA, energy-saving for long-time use
• Dual wiring solutions: prewired harness and traditional welding terminal for flexible installation
• 24AWG/26AWG wire, standard length 150mm/300mm, customized wire length available
• 4-8N moderate operating force, comfortable touch and stable triggering performance
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to cold and hot working conditions
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation ability
• Superior electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to guarantee circuit safety
• Rich head styles: concave, flat, round, square and other customized shapes
• Dot & Ring dual lamp types, single color, dual color and tri-color LED optional
• Full LED voltage range: 3V~220V AC/DC universal for diverse power systems
• Various contact configurations: NO, NC, 1NO1NC, 2NO2NC, prolonged pulse etc.
• Multiple shell lengths and surface crafts: anodized & oxide multi-color options
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Support full customization for appearance and internal parameters
• Compliant with CE EN 60947-5-1 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 30mm
• Core Function: Segmented Dimming
• Operation Mode: Momentary
• Main Material: SUS304 + Aluminum Oxide
• Protection: IK69 Anti-impact + IP68 Waterproof
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Dot / Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1

Product Advantages

This 30mm segmented dimming piezo switch is a professional component specially designed for brightness adjustment. It adopts SUS304 stainless steel and aluminum oxide materials, featuring flame retardant, high temperature resistance, rust and corrosion resistance. With IK69 anti-impact and IP68 waterproof dual protection, it can work stably in complex outdoor and industrial environments. The momentary operation mode matches the use logic of segmented dimming, which is convenient for stepless and segmented brightness adjustment. The product supports 3-24V wide voltage and ultra-low operating current, which is energy-saving for long-term operation. Two wiring methods of prewired and welding meet different installation requirements. Gold and silver contacts ensure stable electrical conduction and long service life. It has two temperature adaptation ranges and excellent electrical indicators. A full range of customizable options including head shape, lamp type, lamp color, contact mode and shell specifications are available to meet personalized project needs. With 1 million mechanical and electrical cycles and 40000-hour total lifespan, it is reliable and durable. Compliant with CE international standards, it is the ideal choice for smart lighting systems, industrial control panels and various waterproof electronic equipment.

Applications

• Smart lighting systems and segmented brightness adjustment control switches
• Commercial lighting, stage lighting dimming and triggering components
• Industrial control panels and anti-collision waterproof operation buttons
• Outdoor electronic equipment and wet environment control modules
• Custom electronic devices and equipment dimming control units
• Low-voltage electrical systems and intelligent terminal touch switches

FAQ

1. What is the installation size and core function of this switch?
The mounting hole is 30mm, and it is a momentary piezo switch with segmented dimming function.

2. What protection levels and main materials does it have?
It has IK69 anti-impact and IP68 waterproof grade; made of SUS304 stainless steel and aluminum oxide.

3. What are the voltage and current parameters?
Rated voltage 3-24V, working current is below 20mA with low power consumption.

4. What temperature range and operating force?
Two ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring methods and wire specifications?
Support welding and prewired (24AWG/26AWG), 150mm/300mm length, customizable.

7. What lamp types and customizable items are available?
Dot lamp and ring lamp are optional; head style, LED, contact and shell can be customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1.

9. What main scenarios is it suitable for?
Mainly used for smart lighting dimming, industrial control, outdoor waterproof equipment and electronic devices.

The post 30mm Segmented Dimming IK69 Stainless Steel Momentary Piezoelectric Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 25mm mounting size, compatible with most outdoor equipment and lighting control panels
• Professional stepless dimming function, realizing continuous brightness adjustment for lighting systems
• IP68 waterproof and dustproof grade plus optional IK69 anti-impact level, perfect for rainy outdoor environments
• Combined material design: SUS304 stainless steel head + aluminum oxide housing, anti-rust & anti-corrosion
• Flame retardant, high temperature resistant, anti-collision and pressure resistant for harsh outdoor conditions
• Exquisite precision manufacturing, bright and long-lasting surface color, support personalized customization
• Rated voltage 3-24V, ultra-low working current below 20mA, energy saving for long-term operation
• 4-8N moderate operating force, comfortable touch and stable pressure triggering performance
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to extreme ambient temperatures
• Dual wiring solutions: prewired harness and traditional welding terminal for flexible installation
• 24AWG/26AWG wire specification, standard length 150mm/300mm, customizable wire length
• Gold and silver optional contact materials, excellent conductivity and oxidation resistance
• Outstanding electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to ensure circuit safety
• Diversified head styles: concave, flat, round, square and customized shapes
• Dot lamp & ring lamp available, multiple single/dual/tri-color LED options
• Full LED voltage range covering AC and DC 3V~220V to match various power supplies
• Rich contact configurations: NO, NC, 1NO1NC, 2NO2NC, prolonged pulse type
• Multiple shell lengths and surface treatments including anodized & oxide finishes
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Compliant with CE EN 60947-5-1 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 25mm
• Core Function: Stepless Dimming
• Main Material: SUS304 + Aluminum Oxide
• IP Rating: IP68 Waterproof, Optional IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Dot & Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1

Product Advantages

This 25mm metal piezo switch is specially developed for outdoor and rainy working environments. It adopts IP68 high waterproof grade and optional IK69 anti-impact performance, which can resist rain, dust and external impact effectively. The combination of SUS304 stainless steel and aluminum oxide material brings excellent corrosion, rust, flame and high temperature resistance. Equipped with professional stepless dimming function, it can realize smooth and continuous brightness adjustment for lighting equipment. The product supports 3-24V wide voltage and ultra-low current operation, which is energy-saving for long-term use. Two wiring methods of prewired and welding meet different installation requirements. Gold and silver contacts ensure stable electrical conduction and long service life. It adapts to two temperature ranges, covering low temperature and high temperature outdoor scenes. A full set of customized options for head shape, lamp style, contact mode and shell specifications are available. With 1 million mechanical and electrical cycles and 40000-hour total lifespan, it is durable and reliable. Complying with CE international standards, it is an ideal waterproof control component for outdoor lighting, outdoor machinery and rainy-day operating equipment.

Applications

• Outdoor landscape lights, street lamps and courtyard lamp stepless dimming control switches
• Rainproof outdoor mechanical equipment and field operation control buttons
• Open-air electrical cabinets and distribution box waterproof signal control components
• Outdoor intelligent devices and waterproof electronic product touch modules
• Amusement facility lighting and all-weather operation control parts
• Marine peripheral equipment and wet environment dimming control units

FAQ

1. What is the installation size and core function of this switch?
The mounting hole is 25mm, and it is a piezo switch with professional stepless dimming function.

2. What protection levels and main materials does it use?
It has IP68 waterproof & dustproof grade and optional IK69 anti-impact grade; head is SUS304 stainless steel, shell is aluminum oxide.

3. What are the voltage and current parameters?
Rated voltage 3-24V, working current is below 20mA with low power consumption.

4. What temperature range and operating force?
Two optional temperature ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring methods and wire specifications?
Support welding and prewired connection; 24AWG/26AWG wire, 150mm/300mm length, customizable.

7. What lamp types and customizable items are available?
Dot lamp and ring lamp are optional; head style, LED, contact and shell can be fully customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1.

9. What environments and equipment is it suitable for?
Specially designed for outdoor and rainy environments, widely used in outdoor lighting, outdoor machinery and waterproof electronic devices.

The post IP68 25mm Stepless Dimming Metal Pressure Piezo Switch For Outdoors And Rainy Days appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting aperture, widely compatible with mainstream industrial and outdoor control panels
• Momentary pressure operation mode, ideal for instantaneous signal triggering and temporary circuit control
• Built-in ring light design for clear equipment status indication in dim environments
• SUS304 stainless steel head + aluminum oxide housing, anti-rust, corrosion and wear resistant
• Excellent physical properties: anti-collision, pressure resistance, flame retardant and high temperature resistance
• IP68 waterproof & dustproof grade, IK69 anti-impact level available for harsh environments
• Precision manufacturing process, bright and durable surface finish, support personalized customization
• Rated voltage 3-24V, ultra-low working current below 20mA, energy-saving for long-term operation
• 4-8N moderate operating force, comfortable touch and stable pressure triggering performance
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to cold and hot conditions
• Dual wiring solutions: traditional welding terminal and 24AWG/26AWG prewired harness
• Standard wire length 150mm/300mm, customized wire length is available on request
• Gold and silver optional contact materials, outstanding conductivity and anti-oxidation ability
• Superior electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to ensure circuit operation safety
• Diversified head styles: concave, flat, round, square and customized shapes
• Multiple lamp choices: ring lamp, dot lamp, illuminated & non-illuminated options
• Rich LED colors: single color, dual color and tri-color with full AC/DC voltage range
• Various contact configurations: NO, NC, 1NO1NC, 2NO2NC, prolonged pulse type
• Multiple shell lengths and surface treatments: anodized & oxide multi-color finishes
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Compliant with CE EN 60947-5-1 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 22mm
• Operation Mode: Momentary Pressure Type
• Main Material: SUS304 + Aluminum Oxide
• IP Rating: IP68, Optional IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Ring & Dot LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1

Product Advantages

This 22mm ring light piezo switch adopts high-quality SUS304 stainless steel and aluminum oxide materials, with flame retardant, high temperature, anti-rust and anti-corrosion performance. Equipped with IP68 full waterproof and dustproof protection and optional IK69 anti-impact function, it can work stably in wet, dusty and impact-prone industrial and outdoor environments. The momentary pressure structure is sensitive in response, which is suitable for instantaneous signal triggering. The built-in ring LED light clearly displays equipment operating status even in dim spaces. It supports 3-24V wide voltage and ultra-low current operation, which is energy-saving for long-term use. Welding and prewired dual wiring methods meet different installation requirements. Gold and silver contacts ensure stable electrical conduction and long service life. It has two temperature adaptation ranges and complete electrical indicators, with 1 million mechanical and electrical cycles and 40000-hour total lifespan. Rich customized options for head shape, lamp style, contact mode and shell specifications can satisfy personalized project demands. Complying with CE international standards, it is a reliable control component for industrial equipment, outdoor electrical appliances and various wet working devices.

Applications

• Industrial control panels instantaneous trigger and status indication buttons
• Outdoor electrical equipment and field machinery waterproof control switches
• Wet workshop, mechanical equipment and humid environment operation components
• Low-voltage control systems and intelligent terminal touch switches
• Public facilities and all-weather operation electronic devices
• Testing instruments and signal collection control modules

FAQ

1. What is the installation size and operation mode?
The mounting hole is 22mm, and it is momentary pressure type piezo switch.

2. What are the material and protection levels?
Head is SUS304 stainless steel, shell is aluminum oxide; standard IP68, IK69 anti-impact is optional.

3. Core electrical parameters?
Rated voltage 3-24V, working current is below 20mA with low power consumption.

4. Temperature range and operating force?
Two ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring methods and wire specifications?
Support welding and prewired (24AWG/26AWG), 150mm/300mm length, customizable.

7. About the lamp and customizable items?
Standard ring lamp, dot lamp is optional; LED color, voltage, head and shell can be customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1.

9. Main application scenarios?
Used for industrial equipment, outdoor devices and various wet environment control systems.

The post IP68 22mm SUS304 Momentary Pressure Piezo Switch With Ring Light appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 19mm mounting aperture, widely compatible with 12V equipment panels and control housings
• Momentary touch operation, sensitive piezoelectric triggering for instantaneous signal output
• Dual high protection: IP68 waterproof & dustproof plus IK69 anti-impact for harsh environments
• Premium material combination: SUS304 stainless steel head and aluminum oxide shell
• Excellent physical performance: anti-rust, anti-corrosion, anti-collision, pressure resistance, flame retardant & high temperature resistance
• Exquisite precision manufacturing, durable surface color, full customization available
• Rated voltage 3-24V, specially optimized for 12V power supply systems
• Ultra-low working current below 20mA, energy-saving for long-term continuous operation
• 4-8N moderate operating force, comfortable touch and stable triggering experience
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to extreme cold and hot environments
• Dual wiring solutions: traditional welding terminal and 24AWG/26AWG prewired harness
• Standard wire length 150mm/300mm, customized wire length to meet installation demands
• Gold and silver optional contact materials, great conductivity and anti-oxidation capability
• Superior electrical indicators: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to ensure circuit safety
• Diversified head styles: concave, flat, round, square and customized shapes
• Dot lamp and ring lamp optional, support single color, dual color and tri-color LED
• Full LED voltage range covering AC/DC 3V~220V for various power supplies
• Rich contact configurations: NO, NC, 1NO1NC, 2NO2NC, prolonged pulse type
• Multiple shell lengths and surface treatments: anodized & oxide multi-color finishes
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Compliant with CE EN 60947-5-1 international electrical safety standard

Technical Specifications

Product Attributes

• Mounting Dimension: 19mm
• Operation Mode: Momentary Touch
• Main Material: SUS304 + Aluminum Oxide
• Protection: IP68 Waterproof + IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V (12V Optimized), Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Dot / Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1

Product Advantages

This 19mm piezo touch button is specially customized for 12V systems, equipped with IP68 waterproof, dustproof and IK69 anti-impact dual protection, fully adapting to complex industrial and outdoor environments. It adopts SUS304 stainless steel and high-quality aluminum oxide material, featuring rust prevention, corrosion resistance, flame retardancy and high temperature resistance. The momentary touch structure responds quickly, which is suitable for instantaneous signal triggering. The product has 3-24V wide voltage compatibility and ultra-low operating current, realizing energy-saving operation. Welding and prewired dual wiring methods meet different on-site installation requirements. Gold and silver contacts ensure stable electrical conduction and long service life. Two temperature adaptation ranges enable normal operation in ultra-low and ultra-high temperature scenes. It supports full customization including head shape, lamp style, LED parameters, contact modes and shell specifications to meet personalized project needs. With 1 million mechanical and electrical cycles and 40000-hour total lifespan, the product is durable and reliable. Complying with CE international standards, it is an ideal control component for 12V industrial equipment, smart terminals and wet environment devices.

Applications

• 12V industrial machinery and automation equipment instantaneous touch control buttons
• Smart electronic terminals and intelligent hardware signal trigger modules
• Outdoor electrical devices and field equipment waterproof operation switches
• Workshop machinery in humid, dusty and impact-prone environments
• Laboratory testing instruments and low-voltage circuit control components
• Custom electronic products and embedded touch control units

FAQ

1. What is the installation size and operation type?
The mounting hole is 19mm, and it is momentary touch piezo switch.

2. What protection levels and main materials?
It has IP68 waterproof & dustproof and IK69 anti-impact grades; head is SUS304 stainless steel, shell is aluminum oxide.

3. What are the voltage and current parameters?
Rated voltage 3-24V (optimized for 12V systems), working current below 20mA.

4. Temperature range and operating force?
Two ranges: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring methods and wire specifications?
Support welding and prewired; 24AWG/26AWG wire, 150mm/300mm length, customizable.

7. What customizable parts are available?
Head style, lamp type, LED color & voltage, contact configuration and shell size can be customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1.

9. What main equipment is it suitable for?
Mainly used for 12V industrial equipment, smart devices, outdoor and wet environment control systems.

The post 19mm Touch Button IK69 12V Stainless Steel Momentary Piezo Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting aperture, compatible with most smart devices and industrial control panels
• Momentary operation mode with infinite micro dual chip design for stable and sensitive triggering
• High-end metal shell and SUS304 stainless steel head, anti-corrosion, pressure-resistant, rainproof and waterproof
• Dual protection: IP68 waterproof & dustproof, IK69 anti-impact grade for harsh working conditions
• Rated voltage 3-24V, specially optimized for 24V power supply systems, wide voltage adaptability
• Ultra-low working current below 20mA, energy-saving for long-term continuous operation
• 4-8N moderate operating force, comfortable touch and stable pressing experience
• Dual temperature ranges: -20℃~55℃ and -40℃~+75℃, adapt to extreme cold and hot environments
• Dual wiring solutions: traditional welding terminal and 24AWG/26AWG prewired harness
• Standard wire length 150mm/300mm, customized wire length available for diverse installation
• Gold and silver optional contact materials, excellent conductivity and anti-oxidation performance
• Outstanding electrical performance: max contact resistance 50mΩ, min insulation resistance 1000MΩ
• Withstand 2000VAC (50/60HZ) dielectric strength to ensure circuit operation safety
• Diversified head styles: concave, flat, round, square and customized shapes
• Dot lamp & ring lamp optional, support single color, dual color and tri-color LED
• Full LED voltage range covering AC and DC 3V~220V to match various power sources
• Rich contact configurations: NO, NC, 1NO1NC, 2NO2NC, prolonged pulse type
• Multiple shell lengths and surface treatments including anodized & oxide finishes
• Long service life: 1 million mechanical cycles, 1 million electrical cycles, total 40000 hours
• Compliant with CE EN 60947-5-1 international electrical safety standard
• Versatile design for smart home, smart living and full-range industrial applications

Technical Specifications

Product Attributes

• Mounting Dimension: 16mm
• Operation Mode: Momentary
• Internal Structure: Infinite Micro Dual Chip
• Main Material: SUS304 + High-grade Metal Shell
• Protection: IP68 Waterproof & Dustproof, IK69 Anti-impact
• Temperature Range: -40℃ ~ +75℃
• Operating Force: 4-8N
• Electrical Spec: 3-24V, Working Current ≤20mA
• Contact: Gold / Silver, Multiple Combinations
• Electrical Performance: 50mΩ Max / 1000MΩ Min / 2000VAC
• Lamp: Dot / Ring LED, Multi-color & Multi-voltage
• Shell: Multiple Lengths & Surface Finishes
• Wiring: Welding / Prewired (Custom Wire Length)
• Service Life: 1 Million Cycles, 40000 Hours
• Certification: CE EN 60947-5-1

Product Advantages

This 16mm 24V piezo switch adopts infinite micro dual chip design, delivering sensitive and stable triggering performance. It is built with SUS304 stainless steel and premium metal housing, featuring corrosion resistance, pressure resistance, rainproof and waterproof capabilities. Equipped with IP68 and IK69 dual protection levels, it can operate reliably in complex indoor and outdoor environments. Optimized for 24V circuits and compatible with 3-24V wide voltage range, the switch consumes ultra-low power for long-term use. It supports welding and prewired two wiring methods to meet various installation requirements. Gold and silver contacts ensure stable electrical conduction and long service life. The product adapts to two temperature zones, suitable for both low and high temperature scenarios. A full range of customizable options including head shape, lamp style, contact mode and shell specifications are available. With 1 million mechanical and electrical cycles and 40000-hour total lifespan, it is highly durable. Complying with CE international standards, it is a universal component widely applicable to smart home systems, intelligent terminals and all kinds of industrial equipment.

Applications

• Smart home control panels and intelligent living equipment touch buttons
• Smart electronic devices and wearable equipment trigger modules
• General industrial machinery and automation control switches
• Outdoor electrical facilities and rainproof field operation components
• Low-voltage control systems and embedded electronic devices
• Public intelligent terminals and all-weather control equipment

FAQ

1. What is the mounting size and internal structure of this piezo switch?
The mounting hole is 16mm, and it adopts infinite micro dual chip structure with momentary operation.

2. What protection levels and main materials does it have?
It has IP68 waterproof & dustproof and IK69 anti-impact grade; made of SUS304 stainless steel and high-grade metal shell.

3. What are the voltage and current parameters?
Rated voltage 3-24V (optimized for 24V), working current is below 20mA.

4. What temperature range and operating force?
Two temperature options: -20℃~55℃ and -40℃~+75℃; operating force is 4 to 8N.

5. Contact material and electrical performance?
Contacts are gold and silver; max contact resistance 50mΩ, min insulation resistance 1000MΩ, withstand 2000VAC.

6. Wiring ways and wire specifications?
Support welding and prewired; 24AWG/26AWG wire, 150mm/300mm length, customizable.

7. What customizable parts are available?
Head style, LED lamp, contact configuration and shell size can be fully customized.

8. Service life and executive standard?
Mechanical and electrical life reach 1 million times, total lifespan 40000 hours; comply with CE EN 60947-5-1.

9. What main application fields?
Widely used for smart home, smart devices and various industrial equipment.

The post 16mm IK69 24V Stainless Steel Momentary Piezo Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.
