• Standard 22mm mounting hole for industrial panel standard installation
• Integrated waterproof structure adapts to dusty and humid workshop environment
• Red rotary head design, obvious identification for emergency operation
• Non-illuminated simple practical design for general safety control
• Dual operation mode: Maintained latching / Momentary self-resetting optional
• Fixed 1NO1NC contact combination to meet most industrial circuit needs
• Plastic bezel and plastic shell material, lightweight and cost-effective
• Silver contact material, stable conductivity and long service life
• Compliant with EN60947 and IEC60947-5-1 international safety standards
• High voltage withstand performance: AC-15 380V/220V, DC-13 220V/110V
• Rotary reset operation, simple and quick to restore normal work
• Professional emergency shutdown function for mechanical safety protection

Technical Specifications

Product Attributes

• Bezel: Plastic
• Shell Material: Plastic
• Head Material: Plastic
• Head Type: Rotary
• Head Color: Red
• Lamp: Non-Illuminated
• Contact Material: Silver
• Contact Operation: 1NO + 1NC

Product Advantages

This 22mm waterproof 1NO1NC emergency stop switch adopts full plastic structure with red rotary reset head. Built-in waterproof design can adapt to humid and dusty industrial workshops. It supports maintained latching and momentary two working modes, fixed 1NO1NC contact configuration, perfectly matching conventional safety control circuits. Comply with EN60947 and IEC60947-5-1 industrial safety standards, with stable AC and DC voltage load capacity. Simple rotary reset operation, cost-effective and durable, is the preferred safety component for standard industrial machinery and automation equipment.

Applications

• 22mm panel waterproof plastic emergency stop button for dusty humid workshop
• Industrial production machinery 1NO1NC non-illuminated safety switch
• Automation equipment control panel maintained & momentary E-stop button
• Packaging machinery, conveyor equipment emergency shutdown push button
• Electrical cabinet and mechanical equipment standard safety protection switch

FAQ

1. What is the mounting size?
Standard 22mm mounting hole size, suitable for conventional industrial panel installation.

2. Does it support dual operation modes?
Yes, both maintained latching and momentary self-resetting types are available.

3. What is the contact configuration?
Fixed 1NO1NC contact combination, suitable for most safety control circuits.

4. Is this emergency button waterproof?
Yes, it adopts waterproof construction, suitable for humid and dusty workshop environments.

5. Does it follow international industrial standards?
Yes, it complies with EN60947 and IEC60947-5-1 safety standards.

6. Is it illuminated type?
No, this model is non-illuminated version with pure mechanical control.

The post 22mm Emergency Stop Switch Waterproof 1NO1NC Maintained/Momentary Push Button appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting size, suitable for universal control panel installation
• Two working modes: 2-position (2P) and 3-position (3P) maintained operation
• Key operated design for authorized access and equipment safety protection
• Classic 1NO1NC normally open and normally closed contact configuration
• Silver contact material for excellent conductivity and stable circuit connection
• Full plastic bezel, head and shell, lightweight and durable structure
• Black appearance, simple and practical for various control cabinets
• Non-illuminated design, simple structure and low failure rate
• Maintained position function, keep stable state after switching
• Professional safety switch for restricting unauthorized operation
• Compact structure, easy wiring and long service life

Technical Specifications

Product Attributes

• Mounting Dimension: 16mm
• Operation Mode: 2P / 3P Maintained Selector
• Contact Type: 1NO1NC
• Contact Material: Silver
• Bezel: Plastic
• Head: Black Plastic
• Shell: Plastic
• Lamp Status: Non-Illuminated
• Operation Type: Key Operated Lock Switch

Product Advantages

This 16mm key operated selector switch adopts standard 16mm installation size, compatible with most industrial control panels. It supports 2-position and 3-position maintained switching, and is equipped with 1NO1NC contact layout to meet diverse circuit control demands. The silver contacts ensure good electrical conductivity and stable operation. The whole set uses plastic materials for bezel, head and shell, which is lightweight, durable and cost-effective. The key locking design effectively prevents unauthorized operation of equipment and improves operational safety. With black appearance and non-illuminated structure, this switch features simple installation, convenient wiring and reliable performance for long-term use.

Applications

• Industrial control cabinet key-locked circuit selection and power control
• Mechanical equipment operation panel permission management switch
• Automation machine tool safety access control component
• Electrical equipment and power distribution box lock-type selector switch
• Public facilities and special equipment anti-misoperation control switch

FAQ

1. What is the standard mounting size of this key switch?
The standard installation aperture is 16mm, which is widely used for conventional control panels.

2. How many position modes does this selector switch support?
It has two optional modes: 2-position (2P) and 3-position (3P) maintained position.

3. What is the contact configuration and contact material?
It adopts 1NO1NC (1 normally open + 1 normally closed) configuration, and the contact is made of silver.

4. What materials are used for the switch body?
The bezel, head and outer shell are all made of plastic, and the head color is black.

5. Does this key switch have an indicator lamp?
No, it is designed as non-illuminated type without built-in indicator lamp.

6. What is the feature of maintained position design?
After switching the gear by key, the switch will keep the current state steadily without accidental reset.

7. What are the main application scenarios?
Mainly used for industrial control cabinets, mechanical equipment and electrical devices that need key permission control.

The post 16MM Key Operated Selector Switch Black 2P/3P Maintained Position with 1NO1NC Configuration appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting aperture, compatible with most industrial control panels and cabinets
• Pure momentary operation mode, automatic reset after release for jog and signal control
• Full plastic structure including bezel, head and shell, lightweight and cost-effective
• Flat head design, comfortable touch and neat appearance for panel assembly
• Built-in illuminated indicator, optional Red and Green LED colors for status distinction
• Standard 1NO+1NC contact configuration, widely used for various control circuits
• Complete electrical parameters, stable performance for AC and DC working circuits
• Compliant with GB/T14048.5, EN/IEC60947-5-1 international and national standards
• Low failure rate, long service life for long-term continuous industrial operation
• Simple installation and wiring, no complicated assembly required
• Universal design for mechanical equipment and electrical control systems

Technical Specifications

Product Attributes

• Mounting Dimension: 22mm
• Operation Type: Momentary / Self-reset
• Head Style: Flat
• Body Material: Plastic (Bezel, Head, Shell)
• Default Head Color: Green
• LED Color: Green, Red
• Contact: 1NO + 1NC
• Insulation Voltage: 600V
• Impulse Voltage: 2.5kV
• Thermal Current: 10A
• AC Parameter: 240V / 3A
• DC Parameter: 250V / 0.27A

Product Advantages

This 22mm flat momentary push button adopts full plastic construction, which is lightweight, economical and easy to install. It only supports momentary self-reset operation, which is specially designed for jogging, instantaneous start and signal triggering work. Equipped with 1NO+1NC universal contacts and dual-color LED indicators (red and green), it can clearly display equipment operating status. The product has complete electrical performance and strictly complies with GB and IEC electrical standards, ensuring safe and stable operation in AC and DC circuits. With simple structure, sensitive operation and low failure rate, it is a practical and cost-effective control component for various industrial electrical equipment.

Applications

• Industrial control cabinet instantaneous start, stop and jog control buttons
• Automation machinery equipment operation panel signal trigger switch
• Production line equipment temporary operation and manual control components
• Electrical box and distribution cabinet auxiliary signal control switch
• General electromechanical device momentary operation and status indication button

FAQ

1. What operation mode does this push button adopt?
It is a pure momentary self-reset type, which will automatically rebound after being pressed and released.

2. What materials are used for the whole switch?
The bezel, button head and outer shell are all made of high-quality plastic.

3. What contact configuration does it have?
It adopts classic 1NO+1NC (1 normally open + 1 normally closed) contact combination.

4. Does it have indicator light and optional colors?
Yes, it is an illuminated model. Optional LED colors are green and red.

5. What are the core electrical parameters?
Ui 600V, Uimp 2.5kV, Ith 10A; AC 240V/3A, DC 250V/0.27A.

6. What standards does the product comply with?
It complies with GB/T14048.5 and EN/IEC60947-5-1 electrical safety standards.

7. What are the main application scenarios?
It is widely used for instantaneous control and signal indication of industrial control cabinets, automation equipment and electromechanical devices.

The post 22MM Illuminated Flat Button Switch Momentary Plastic Push Button with 1NO1NC Contacts appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Universal 22-30mm mounting size, compatible with two mainstream panel hole sizes for wide applicability
• 2P (2-position) and 3P (3-position) optional configurations to meet different gear selection requirements
• Dual operation modes: maintained (latching) and momentary (reset) for flexible circuit control logic
• Standard 1NO1NC (1 Normally Open + 1 Normally Closed) contact structure for signal switching
• High-purity silver contacts, low contact resistance, excellent conductivity and anti-oxidation performance
• Crimp type connection terminal, fast wiring, firm connection and suitable for mass assembly
• Full plastic structure including bezel, rotary head and shell, good insulation and impact resistance
• Uniform black appearance, classic industrial style matching most control panels and equipment
• Non-illuminated design, simple structure, fewer vulnerable parts and low failure rate
• Rated thermal current 10A, supports AC-15 and DC-13 load categories for diverse voltage systems
• Compliant with EN60947 and IEC60947-5-1 international standards, safe and reliable for global use
• Compact body, easy installation and maintenance, cost-effective for industrial projects

Full Technical Specifications

Product Attributes

• Mounting Dimension: 22mm & 30mm Dual Universal Size
• Position: 2P / 3P Optional
• Operation: Maintained + Momentary Dual Modes
• Contact: 1NO1NC, Silver Material
• Wiring: Crimp Connection
• Main Material: Plastic (Bezel / Head / Shell)
• Color: Black
• Lamp: Non-Illuminated
• Rated Current: 10A
• Load Type: AC-15, DC-13
• Compliance: EN60947, IEC60947-5-1

Product Advantages

This 22-30mm universal rotary switch is a versatile industrial control component. It adapts to two common panel opening sizes of 22mm and 30mm, greatly improving equipment compatibility. With selectable 2-position and 3-position gears, as well as maintained and momentary dual working modes, it can meet complex circuit control demands. The 1NO1NC silver contact ensures stable current transmission and long service life. The crimp terminal design simplifies wiring work and is suitable for batch production and on-site installation. The all-plastic structure has good insulation and anti-collision performance, and the black non-illuminated rotary head has a simple structure with low failure risk. The product reaches 10A rated current and supports AC-15 and DC-13 typical load categories, covering most AC and DC low-voltage control circuits. It strictly follows EN60947 and IEC60947-5-1 international electrical standards, with reliable quality for export to global markets. It is an economical and practical choice for industrial control and mechanical equipment.

Application Scenarios

This universal rotary switch is widely sold in Europe, North America, Southeast Asia and other global regions, focusing on industrial low-voltage control fields.

• Indoor electrical control cabinets and power distribution box gear switching components
• Industrial automation equipment and production line mode selector switches
• Engineering machinery and mobile mechanical control panel accessories
• Low-voltage AC/DC control systems and signal conversion modules
• Testing instruments and laboratory equipment function adjustment knobs
• Commercial electromechanical devices and general industrial electrical appliances

FAQ

1. What mounting sizes and position options does this switch have?
It supports 22mm and 30mm two panel sizes, with 2P (2-position) and 3P (3-position) optional gears.

2. What operation modes and contact structure are equipped?
It has maintained (latching) and momentary (reset) dual modes, adopting standard 1NO1NC contact configuration.

3. What is the contact material and wiring type?
The contact is made of silver; the terminal adopts crimping connection for fast and firm wiring.

4. What are the material and appearance features?
The bezel, rotary head and shell are all made of plastic; overall color is black, and there is no indicator lamp.

5. What are the electrical parameters and load categories?
Rated thermal current is 10A; AC-15 for 380VAC/220VAC, DC-13 for 220VDC/110VDC.

6. Which international standards does the product comply with?
It is manufactured in accordance with EN60947 and IEC60947-5-1 international electrical standards.

7. What is the difference between maintained and momentary modes?
Maintained mode locks the position after rotation; momentary mode automatically resets when the hand is released.

8. What are the advantages of 22-30mm universal size?
It is compatible with two mainstream panel holes, reducing model types and improving application scope.

9. What main equipment is this switch suitable for?
Widely used in industrial control cabinets, automation machinery, engineering equipment and low-voltage systems worldwide.

The post 22-30mm Rotary Switch Black 2P/3P Maintained/Momentary 1NO1NC appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting hole for small and medium equipment panel installation
• Classic red mushroom head design, easy to recognize and press in emergency
• IP65 professional dustproof and waterproof rating for harsh workshop environment
• Rotary reset structure, simple and quick to restore working state
• Dual operation mode: Maintained latching / Momentary self-resetting optional
• Two contact combinations: 1NO+1NC , 2NO+2NC for circuit matching
• Full plastic bezel and shell material, lightweight and cost-effective
• Non-illuminated design, suitable for conventional mechanical safety control
• Silver contact material, stable conduction, anti-aging and long service life
• Compact structure, easy to install, integrate and replace
• Professional emergency shutdown function to protect personnel and machine safety

Technical Specifications

Product Attributes

• Bezel: Plastic
• Shell Material: Plastic
• Head Material: Plastic
• Head Type: Mushroom
• Head Color: Red
• Lamp: Non-Illuminated
• Contact Material: Silver
• Contact Operation: 1NO+1NC , 2NO+2NC

Product Advantages

This 16mm IP65 mushroom head emergency stop switch adopts integrated plastic structure and obvious red mushroom head appearance. It supports rotary reset, maintained and momentary dual working modes, with two contact options of 1NO1NC and 2NO2NC to meet different circuit design needs. IP65 dustproof and waterproof performance adapts to dusty, humid factory workshops. Silver contact ensures stable electrical performance, non-illuminated design is simple and practical, compact and easy to install, cost-effective for various small and medium industrial equipment safety emergency stop control.

Applications

• 16mm panel IP65 mushroom head emergency stop button for dusty humid workshop
• Small and medium automation machinery non-illuminated safety E-stop switch
• Packaging equipment, conveyor line and processing machine emergency shutdown button
• Electrical control cabinet mechanical equipment rotary reset safety button
• Light industrial machinery DIY equipment 1NO1NC 2NO2NC emergency switch

FAQ

1. What is the mounting hole size?
Standard 16mm mounting hole, suitable for 16mm reserved panel installation.

2. What protection level does it have?
IP65 dustproof and waterproof grade, can be used in humid and dusty workshop environment.

3. What operation modes are available?
Supports maintained latching and momentary self-resetting two types, with rotary reset way.

4. What contact combinations are optional?
1NO+1NC and 2NO+2NC two contact configurations for different circuit requirements.

5. Is this button illuminated?
No, it is non-illuminated version, belongs to pure mechanical emergency stop control.

6. What material is the shell and head?
Adopt full plastic material, light weight, cost-effective and durable for conventional industrial use.

The post 16mm Mushroom Head Emergency Stop Switch with 1NO1NC Contacts IP65 Rated Maintained/Momentary Rotary Reset appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting diameter for panel installation
• Classic red mushroom head design for obvious emergency recognition
• IP67 high-level waterproof and dustproof protection for harsh environments
• Illuminated dot lamp type with multiple LED color options
• Optional LED color: Blue, Green, Red, White, Yellow
• Fixed 1NO+1NC contact configuration for universal safety circuit
• Full plastic bezel, head and shell material, lightweight and cost-effective
• Plug-in connection design for fast and convenient wiring
• Silver contact and silver PIN material for stable conduction
• Integrated waterproof structure prevents water and dust intrusion
• Wide application for civil, medical, marine, automotive and industrial devices

Technical Specifications

Product Attributes

• Bezel: Plastic
• Shell Material: Plastic
• Head Material: Plastic
• Head Type: Mushroom
• Head Color: Red
• Lamp: Illuminated
• Lamp Type: Dot
• LED Color: Blue, Green, Red, White, Yellow
• Contact Material: Silver
• PIN Material: Silver
• Operation of Contact: 1NO+1NC
• Mounting diameter: 16mm
• Connection: Plug in

Product Advantages

This 16mm plastic illuminated mushroom head emergency stop button adopts IP67 waterproof structure and full plastic body. Built-in dot style LED supports multiple color options to indicate working status clearly. Standard 1NO1NC contact meets most safety control circuit requirements. Plug-in wiring is easy to install and replace. Silver contact and pin ensure stable electrical performance. IP67 dustproof and waterproof design adapts to wet, dusty and semi-outdoor environments, ideal for elevators, medical equipment, marine facilities, automotive devices, home appliances and PC modding safety emergency stop control.

Applications

• 16mm panel IP67 illuminated mushroom head emergency stop button
• Elevator and access control system safety emergency push button
• Medical facility and hospital equipment waterproof illuminated E-stop switch
• Marine and boat wet environment dustproof emergency control button
• Automotive, home appliance and PC modding customized LED stop switch

FAQ

1. What is the mounting size?
Standard 16mm mounting diameter, suitable for 16mm reserved panel holes.

2. What is the waterproof grade?
IP67 professional waterproof and dustproof level, suitable for wet and dusty occasions.

3. Does it have LED light?
Yes, it is illuminated type with dot lamp design.

4. What LED colors are available?
Blue, Green, Red, White and Yellow optional.

5. What is the contact configuration?
Fixed 1NO+1NC contact combination for general safety circuits.

6. Wiring method?
Plug-in connection design, easy and fast wiring installation.

7. What scenarios is it suitable for?
Widely used in elevators, access control, medical equipment, marine, automotive, home appliances and PC modding.

The post 16mm Plastic Illuminated Emergency Stop Push Button IP67 1NO1NC appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 16mm mounting diameter for standard panel hole installation
• Classic red mushroom head design, eye-catching for emergency operation
• IP67 high waterproof and dustproof grade for harsh wet and dusty environments
• Non-illuminated mechanical type, simple structure and stable performance
• Dual operation type: Momentary self-resetting and Maintained latching optional
• Standard 1NO+1NC contact configuration for most safety control circuits
• High-quality gold contact material for good conductivity and oxidation resistance
• Silver PIN terminal, reliable plug-in connection and long service life
• Rated 5A current, wide voltage range 1.5V~250V AC/DC universal
• Full plastic bezel, head and shell, lightweight, cost-effective and corrosion-resistant
• Plug-in wiring method, easy installation, replacement and maintenance
• Professional IP67 sealed structure prevents dust and water intrusion

Technical Specifications

Product Attributes

• Bezel: Plastic
• Shell Material: Plastic
• Head Material: Plastic
• Head Type: Mushroom
• Head Color: Red
• Lamp: Non-Illuminated
• Contact Material: Gold
• PIN Material: Silver
• Operation of Contact: 1NO+1NC
• Operation type: Momentary, Maintained
• Mounting diameter: 16mm
• Connection: Plug in
• Rated Current & Voltage: 5A, 1.5V~250V AC/DC

Product Advantages

This 16mm IP67 non-illuminated mushroom head emergency stop switch adopts full plastic lightweight structure and IP67 sealed waterproof design. It supports momentary and maintained dual working modes, with standard 1NO1NC contact matching most industrial and civil safety circuits. Gold contact brings excellent conductivity and anti-oxidation ability, silver pin ensures stable plug-in connection. Wide 1.5V~250V AC/DC voltage and 5A current rating adapt to most power systems. Cost-effective, dustproof and waterproof, perfectly suitable for marine, medical, new energy and access control equipment emergency safety cutoff.

Applications

• 16mm panel IP67 plastic mushroom head waterproof emergency stop button
• Marine and boat wet environment dustproof non-illuminated safety switch
• Medical facility and hospital equipment mechanical emergency stop control
• New energy equipment and automation system 1NO1NC protection button
• Access control cabinet and intelligent equipment IP67 emergency shutdown switch

FAQ

1. What is the mounting size?
Standard 16mm mounting diameter, fits 16mm reserved panel mounting holes.

2. What is the waterproof level?
IP67 professional dustproof and waterproof rating, suitable for humid, dusty indoor and light outdoor environments.

3. Does it support two working modes?
Yes, both momentary self-resetting and maintained latching types are available.

4. What is the contact specification?
Adopts standard 1NO+1NC contact configuration for universal safety circuits.

5. What are the electrical parameters?
Rated current 5A, wide voltage 1.5V~250V compatible with AC and DC.

6. What material are the contacts and pins?
Contact is gold material, PIN terminal is silver material, anti-oxidation and stable conduction.

7. What application scenarios is it suitable for?
Widely used in marine, medical equipment, new energy devices and access control system safety emergency stop.

The post Plastic Material Emergency Stop Switch Button 16mm Mushroom Head IP67 Waterproof Emergency Stop 1NO1NC appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• 2-position lever rotary design with oversized plastic push button, large contact area for comfortable and accurate operation
• 22mm to 30mm universal mounting hole, compatible with most industrial control panels and equipment housings
• Dual operation modes: latching and momentary, meets fixed gear and temporary trigger control demands
• Multiple contact combinations: 2NO, 1NO1NC, 2NO2NC for single and multi-circuit layout
• Wide voltage range from 1V to 250V AC, adaptable to various low and medium voltage systems
• Rated load 5A 250VAC, stable performance for conventional industrial control circuits
• Full plastic body, lightweight, excellent insulation, impact and wear resistance
• Silver contacts and copper pins, reliable conductivity and long service life
• IP40 dustproof grade, works steadily in ordinary indoor and workshop environments
• Plug-in pin terminal, fast wiring and disassembly, convenient for mass assembly and maintenance
• Optional button colors: red, green, black for different equipment collocation
• Wide operating temperature: -20℃ ~ +55℃, fits most conventional working conditions
• Simple lever mechanism, compact structure, low failure rate and easy installation
• Pure mechanical structure without smart modules, high cost performance for bulk procurement

Full Technical Specifications

Product Attributes

• Installation Size: 22mm ~ 30mm Universal Panel Hole
• Structure: 2 Position Lever Rotary Selector
• Operation Mode: Latching + Momentary Dual Modes
• Switch Logic: Standard ON-OFF
• Contact Type: 2NO / 1NO1NC / 2NO2NC Optional
• Contact: Silver Material
• Pin: Copper Material
• Terminal: Pin Terminal, Plug-in Connection
• Body & Button: Full Plastic
• Button Color: Red / Green / Black Selectable
• Protection: IP40 Dustproof
• Rated Spec: 5A 250V AC
• Applicable Voltage: 1V ~ 250V Wide Range
• Temp Range: -20℃ ~ +55℃
• Structure: Pure Mechanical (Non-smart)

Product Advantages

This 2-position lever rotary switch is a cost-effective general industrial control component. The oversized plastic push button brings large operation area and clear feedback, which is friendly for frequent operation. The 22mm-30mm adjustable mounting size has strong compatibility with various control panels. It supports latching and momentary dual modes, together with multiple contact combinations, to meet diversified circuit design requirements. With a wide voltage coverage from 1V to 250V, it can be used in most low and medium voltage AC systems. The all-plastic body features excellent insulation and impact resistance, suitable for ordinary workshop environments. Silver contacts and copper pins ensure stable current transmission and long service life. IP40 dustproof performance prevents dust from entering and affecting internal components. Plug-in pin terminals simplify wiring work and reduce later maintenance difficulty. Multiple color options make it easy to match different equipment styles. The lever structure is simple and reliable, with low failure rate. As a universal switch, it is exported to many global regions and widely used in industrial machinery and general electrical equipment.

Application Scenarios

This universal rotary selector switch is sold to Europe, North America, Southeast Asia and other global markets, mainly for general industrial control equipment.

• Industrial machinery and production line equipment gear selector switches
• Workshop control panels and low-voltage ON-OFF control components
• General electromechanical devices and auxiliary power control knobs
• Electronic DIY projects and customized circuit control modules
• Laboratory instruments and ordinary testing equipment buttons
• Commercial electrical appliances and indoor power distribution accessories

FAQ

1. What is the mounting size and basic function?
The mounting hole ranges from 22mm to 30mm; it is a 2-position ON-OFF lever rotary switch.

2. What operation modes and contact types are available?
It supports latching and momentary modes; optional contacts include 2NO, 1NO1NC and 2NO2NC.

3. What are the materials of contacts and pins?
Contacts are made of silver, and pins adopt copper material for stable conduction.

4. What is the protection level and main material?
IP40 dustproof grade; the whole switch and button are made of plastic.

5. What are the voltage and current parameters?
Rated 5A 250V AC, applicable voltage range is 1V to 250V.

6. What wiring method does it use?
It uses pin terminal with plug-in connection for quick assembly.

7. Are there multiple colors for the push button?
Yes, optional colors: red, green and black.

8. What is the working temperature range?
It can work stably at -20℃ to +55℃.

9. What equipment is this switch suitable for?
Widely used in industrial machinery, control panels and general electrical equipment worldwide.

The post 2 Position Rotary Switches Lever Selector 2No Rotary Head Big Plastic Push Button Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• 22mm to 30mm universal mounting hole, compatible with most industrial control panels and equipment housings
• Dual operation modes: latching (self-lock) and momentary (self-reset) for flexible ON-OFF control logic
• Compliant with EN 60947-5-1 international standard, CE & RoHS certified for global market access
• Supports AC-15 and DC-13 load categories, ideal for AC & DC electromagnetic loads
• Wide voltage range from 1V to 250V, covers 380V/220V AC and 220V/110V DC systems
• Rated thermal current 10A, impulse withstand voltage up to 2.5kV for excellent electrical safety
• Dual contact combinations: 1NO1NC and 2NO2NC to meet single and dual circuit demands
• Silver contacts and copper pins, low resistance and stable long-term conduction
• Full plastic body and button, lightweight, high insulation and impact resistance
• IP40 dustproof grade, works reliably in ordinary indoor and workshop environments
• Plug-in pin terminal, fast wiring and disassembly, convenient for mass assembly
• Multiple optional colors: red, green, black to match different equipment styles
• Wide operating temperature: -20℃ ~ +55℃, adapts conventional working conditions
• Compact rotary push design, comfortable operation and clear switch feedback
• Pure mechanical structure, no smart modules, low failure rate and easy maintenance

Full Technical Specifications

Product Attributes

• Installation Size: 22mm ~ 30mm Universal Panel Hole
• Operation: Latching + Momentary Dual Modes
• Switch Logic: 2 Position ON-OFF
• Standard: EN 60947-5-1 (Low-voltage control device)
• Load Type: AC-15 (AC electromagnetic), DC-13 (DC electromagnetic)
• Voltage Range: 1V to 250V, compatible with mainstream AC/DC voltage
• Rated Current: 10A Thermal Current
• Withstand Voltage: 2.5kV Impulse Voltage
• Contact: Silver; Pin: Copper
• Contact Type: 1NO1NC / 2NO2NC Optional
• Wiring: Pin Terminal, Plug-in Connection
• Body: Full Plastic, Good Insulation
• Color: Red / Green / Black Selectable
• Protection: IP40 Dustproof
• Temp Range: -20℃ ~ +55℃
• Cert: CE, RoHS
• Structure: Pure Mechanical (Non-smart)

Product Advantages

This 22mm dual-mode rotary push switch is a standard-compliant universal control component. It features 22-30mm adjustable mounting size to fit most control panels worldwide. Combining latching and momentary functions, it meets both fixed power control and temporary signal triggering needs. Manufactured per EN 60947-5-1, it is specially designed for AC-15 and DC-13 electromagnetic loads, performing stably when switching solenoids and electromagnets. The ultra-wide 1V-250V voltage range covers most low and medium AC/DC circuits. Silver contacts and copper pins ensure low resistance and reliable conduction. The all-plastic structure provides superior insulation and anti-impact ability. IP40 dustproof design guarantees stable operation in ordinary workshops. Plug-in terminals simplify installation and maintenance, while multi-color options support personalized equipment matching. With CE and RoHS certifications, it fully complies with European and global import regulations. The wide temperature adaptability and long service life make it a cost-effective choice for industrial machinery, control panels and electronic projects.

Application Scenarios

This certified rotary push switch is widely exported to Europe, North America, Southeast Asia and other global regions, focusing on low-voltage electromagnetic control and general electronic fields.

• Industrial control panels and AC/DC electromagnetic valve control switches
• Production line machinery and equipment ON-OFF & temporary trigger buttons
• Automotive low-voltage circuits and vehicle auxiliary control components
• Laboratory instruments and electromagnetic testing device selectors
• Household & commercial low-voltage electrical appliances control knobs
• Electronic DIY projects and customized electromagnetic circuit modules

FAQ

1. What mounting size and operation modes does this switch support?
It fits 22mm-30mm panel holes, with both latching (self-lock) and momentary (self-reset) operation modes.

2. What international standard and load categories does it follow?
It complies with EN 60947-5-1, rated for AC-15 AC electromagnetic loads and DC-13 DC electromagnetic loads.

3. What is the applicable voltage and rated current?
Voltage range: 1V~250V, compatible with 380V/220V AC and 220V/110V DC; rated thermal current is 10A.

4. What about impulse withstand voltage?
The impulse withstand voltage reaches 2.5kV for enhanced electrical safety.

5. What contact combinations and materials are available?
1NO1NC and 2NO2NC optional; contacts are silver, pins are copper.

6. What wiring method and protection level?
Pin plug-in connection; IP40 dustproof grade for indoor workshop use.

7. What colors are available for the button?
Optional colors: red, green and black.

8. What certifications and working temperature?
CE and RoHS certified; operating temperature: -20℃ to +55℃.

9. What main equipment is this switch used for?
Widely used for industrial machinery, control panels, automotive parts and electronic DIY projects worldwide.

The post 22mm Momentary 2 Position Pushbutton on off Rotary Switches Self-lock Rotary Plastic Button Push Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• 16mm standard mounting hole, mini compact size, perfect for equipment with limited installation space
• Dual position options: 2-position and 3-position to meet multi-gear control requirements
• Dual operation modes: latching (self-lock) and momentary (self-reset) for flexible circuit logic
• ON-(ON) switch function, ideal for temporary signal switching and mode selection
• 3-pin plug-in terminal design, fast wiring, easy assembly and later maintenance
• Multiple contact combinations: 1NO1NC and 2NO2NC, compatible with single and dual circuits
• Silver pins, excellent electrical conductivity and long anti-oxidation performance
• Rated 3A 250VAC, stable performance for low-power AC control circuits
• High-insulation engineering plastic body, lightweight, impact-resistant and corrosion-proof
• Dual protection grades: IP40 for dustproof, IP65 for waterproof & splash-proof, multi-scene adaptation
• Rotary knob with optional red, green and black colors for equipment matching
• No LED light and no smart modules, pure mechanical structure, low failure rate
• Wide operating temperature: -20℃ ~ +55℃, works stably in conventional environments
• Precision electronic structure, durable for long-term frequent operation
• Universal design, compliant with global standards for export sales

Full Technical Specifications

Product Attributes

• Installation Size: 16mm Standard Mini Panel Hole
• Gear: 2 Position / 3 Position Optional
• Operation: Latching + Momentary Dual Modes
• Switch Logic: ON-(ON)
• Pins: 3 Pin, Plug-in Connection
• Contact: 1NO1NC / 2NO2NC Dual Options
• Pin Material: Silver
• Electrical Rating: 3A 250VAC
• Body Material: High-insulation Engineering Plastic
• Knob: Rotary, Multi-color Optional
• Protection: IP40 (Dustproof) / IP65 (Waterproof)
• Indicator Light: None
• Structure: Pure Mechanical (Non-smart)
• Temp Range: -20℃ ~ +55℃
• Core Strength: Mini Size, Dual Protection, Multi-mode

Product Advantages

This 16mm miniature rotary switch is specially designed for compact electronic and electrical equipment. The ultra-small 16mm mounting size perfectly adapts to narrow installation spaces that regular switches cannot fit. It supports 2-position and 3-position gears, together with latching and momentary dual working modes, which can satisfy various temporary triggering and fixed control needs. The 3-pin plug-in terminal greatly improves assembly efficiency and facilitates later maintenance. Equipped with two mainstream contact combinations, it can be applied to single and dual circuit designs. Silver pins ensure stable current transmission and resist oxidation during long-term use. Adopting high-insulation engineering plastic, the whole body features light weight, impact resistance and corrosion resistance. This product provides two protection grades: IP40 for ordinary dust-proof workshops and IP65 for humid & splash-prone environments, with strong scene adaptability. Without LED and smart components, the internal structure is simpler and the failure rate is lower. Multiple knob colors support personalized equipment matching. With a wide temperature range, it can operate reliably in most conventional working environments. It is a cost-effective miniature control component widely recognized in global small equipment and electronic fields.

Application Scenarios

This mini waterproof rotary switch is sold to Europe, North America, Southeast Asia and other global regions, mainly used for compact low-voltage equipment.

• Mini industrial control panels and embedded circuit control components
• Automotive interior mini circuits and vehicle auxiliary function switches
• Smart electronic devices and portable handheld equipment knobs
• Humid small workshop machinery and dust-proof mini equipment
• Electronic DIY projects and customized compact circuit modules
• Household small electrical appliances and low-power control switches

FAQ

1. What is the mounting size and available gear positions?
The standard mounting hole is 16mm; it has 2-position and 3-position two gear options.

2. What operation modes and switch function does it have?
It supports latching (self-lock) and momentary (self-reset) modes, and the switch function is ON-(ON).

3. How many pins and what wiring type is adopted?
It is a 3-pin switch with plug-in connection for quick wiring.

4. What contact combinations can I choose?
Two options: 1NO1NC and 2NO2NC for different circuit designs.

5. What are the electrical specifications and pin material?
Rated 3A 250VAC; pins are made of silver for good conductivity.

6. What material is the switch body and knob?
The main body is made of high-insulation engineering plastic; rotary knob has red, green, black colors optional.

7. What protection levels does this switch support?
It has IP40 dustproof grade and IP65 waterproof grade for different working environments.

8. Does it have LED light or smart functions?
No, it has no LED indicator and no smart modules, it is a pure mechanical switch.

9. What is the working temperature and main applications?
Operating temperature: -20℃ ~ +55℃. Widely used for compact panels, automotive, smart devices and DIY electronics worldwide.

The post 16mm 3-Pin Waterproof Small Rotary Switch 2/3 Position Reset Self Lock Knob 1NO1NC Electronic Structure 3A 250V Button appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.
