• Multiple position options: 2-position and 3-position for flexible multi-gear circuit selection and mode switching
• Dual operation modes: maintained (locking) and momentary, to meet diverse circuit control logic
• Built-in locking mechanism, effectively prevent accidental gear change, improve equipment operation safety
• Durable metal knob, comfortable operation and excellent mechanical durability for long-term use
• Top-grade protection: IK10 mechanical impact resistance (20J impact energy), withstand strong collision
• Dual waterproof grades optional: IP65 and IP66, adapt to wet, splash and outdoor environments
• Excellent electrical performance: contact resistance ≤50mΩ, insulation resistance ≥1000MΩ
• High dielectric strength, minimum 1000VAC withstand voltage, ensure circuit operation safety
• Wide operating temperature: -30℃ ~ +80℃, stable work in extreme cold and high temperature conditions
• Rich contact combinations: 1NO+1NC, 2NO+2NC, 3NO+3NC for single/multi-circuit control
• Silver contacts with optional silver-plated or gold-plated pins, superior conductivity and anti-oxidation
• Nickel brass nut for assembly, sturdy structure and good anti-rust performance
• Plug-in terminal design, fast wiring, convenient for on-site installation and equipment maintenance
• Pure mechanical structure without smart modules, low failure rate and long service life
• Professional design for industrial automation, power equipment and customized electronic devices

Full Technical Specifications

Product Attributes

• Gear Option: 2 Position / 3 Position
• Operation: Maintained + Momentary Dual Modes
• Core Feature: Locking Structure (Anti-accidental Shift)
• Knob: Metal Material
• Mechanical Protection: IK10 High Impact Resistance
• Waterproof: IP65 / IP66 Selectable
• Contact Resistance: ≤50mΩ
• Insulation Resistance: ≥1000MΩ
• Withstand Voltage: ≥1000VAC
• Temp Range: -30℃ ~ +80℃
• Contact Types: 1NO+1NC, 2NO+2NC, 3NO+3NC
• Contact: Silver; Pin: Silver/Gold Plated Optional
• Accessory: Nickel Brass Nut
• Wiring: Plug-in Terminal
• Structure: Pure Mechanical (Non-smart)

Product Advantages

This multi-functional locking rotary switch is specially developed for industrial automation and power equipment. It supports 2-position and 3-position gears, as well as maintained and momentary working modes, which can adapt to various complex circuit control requirements. The built-in locking structure can effectively avoid misoperation caused by collision or human error, greatly improving equipment safety. It reaches IK10 highest mechanical impact resistance standard, which can withstand 20J impact energy and adapt to industrial scenes with frequent collisions. Optional IP65 and IP66 waterproof grades make the switch work stably in humid and splash environments. Equipped with multiple contact combinations from single circuit to multi-circuit, it covers different equipment design demands. Silver contacts and gold/silver plated pins ensure long-term stable conduction and anti-oxidation. The nickel brass nut is sturdy and anti-rust, matching the metal knob perfectly. The plug-in terminal simplifies wiring work and reduces maintenance difficulty. With a wide temperature range from -30℃ to +80℃, it can operate normally in cold northern regions and high-temperature workshops. As a pure mechanical switch, it has a simple structure, reliable quality and long service life, which is a preferred component for global industrial projects.

Application Scenarios

This high-protection locking rotary switch is exported to Europe, North America, Southeast Asia and other global regions, focusing on industrial automation and power control fields.

• Industrial automation production lines and automated control system selector switches
• High-power electrical equipment and low-voltage power distribution cabinet control knobs
• Mechanical devices with collision risks and workshop general machinery components
• Outdoor electrical facilities and IP65/IP66 required waterproof control equipment
• Custom electronic devices and special industrial circuit switching modules
• Instrumentation and testing equipment with strict anti-misoperation requirements

FAQ

1. What gear positions and operation modes does this switch support?
It has 2-position and 3-position optional gears, and supports both maintained and momentary operation modes.

2. Does this switch have anti-misoperation function?
Yes, it is a locking type rotary switch with built-in locking mechanism to prevent accidental gear changes.

3. What are the protection levels?
It meets IK10 mechanical impact resistance standard; waterproof grade is optional IP65 or IP66.

4. What are the core electrical parameters?
Contact resistance ≤50mΩ, insulation resistance ≥1000MΩ, minimum withstand voltage 1000VAC.

5. What is the working temperature range?
It can work stably in the environment of -30℃ to +80℃.

6. What contact combinations are available?
Three options: 1NO+1NC, 2NO+2NC and 3NO+3NC for different circuit designs.

7. What are the materials of contacts, pins and nut?
Contact: silver; pin: silver/gold plated optional; assembly nut: nickel brass.

8. What kind of terminal does it use for wiring?
It adopts plug-in terminal for fast and convenient wiring and maintenance.

9. What main equipment and environments is it suitable for?
Widely used in industrial automation equipment, power devices and custom electronics, suitable for collision-prone and humid industrial environments worldwide.

The post Rotary Switches 2 or 3 Position Maintained Type Lock Automation Equipment Metal Knob Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Multiple mounting diameter: 12mm/16mm/19mm/22mm/25mm/30mm
• Standard 25mm fixed mounting hole for panel installation
• Flat head minimalist industrial design
• Dual operation mode: Momentary / Latching optional
• Switch combination: 1NO1NC / 2NO2NC available
• Rated 2A / 5A 250VAC stable load capacity
• Non-illuminated and Ring LED two illuminating types
• High protection grade: IP67 waterproof + IK08 impact resistance
• Pin terminal welding design, plug-in connection easy installation
• Shell material optional: Nickel Plated Brass / Stainless Steel / Aluminum Alloy
• Silver alloy contact, silver PIN material anti-oxidation
• Max contact resistance 50mΩ, stable electric conduction
• Insulation & Dielectric Intensity up to 2000VAC
• Ambient temperature range: -20°C ~ +55°C
• Mechanical life over 500,000 cycles
• Electrical life over 50,000 cycles
• Panel thickness adaptable: 1~10mm
• Operation pressure: 3~5N, Operation stroke: about 2.5mm
• PA66 base material, anti-aging durable structure
• CE certified for industrial safety standard
• Three Position Maintained / Momentary optional

Technical Specifications

Product Attributes

• Connection: Plug in
• Contact Material: Silver Alloy
• PIN Material: Silver
• Contact Operation: 1NO+1NC / 2NO+2NC Optional
• Position Mode: Three Position Maintained , Three Position Momentary
• Shell Material: Alu Alloy, Brass, Nickel Plated Brass

Product Advantages

This 25mm IP67 IK08 metal push button adopts flat head design with multiple installation apertures optional. It supports momentary and latching dual working modes, matched with 1NO1NC / 2NO2NC contact combination. Made of nickel plated brass, stainless steel and aluminum alloy, it balances conductivity, corrosion resistance and lightweight performance. IP67 waterproof together with IK08 impact resistance adapts to harsh industrial and outdoor environments. 5A 250VAC rated load, long mechanical and electrical lifespan, PA66 base with stable structure, CE certified, easy to install for machinery, automation production lines and power systems.

Applications

• 25mm IP67 IK08 industrial control panel push button
• Automation production line momentary latching metal switch
• Outdoor instrument waterproof impact resistant control button
• Power system 5A high load pin terminal push button
• B2B industrial machinery and equipment replacement switch

FAQ

1. Mounting size?
Multiple sizes optional, standard 25mm mounting hole.

2. Operation mode?
Momentary and Latching two types optional.

3. Protection grade?
IP67 waterproof + IK08 impact resistance.

4. Material option?
Nickel plated brass, stainless steel, aluminum alloy optional.

5. Lifespan & certification?
500k+ mechanical cycles, 50k+ electrical cycles, CE certified.

The post Metal Push Button Switch IP67 IK08 5A Nickel Plated Brass/Stainless Steel/Aluminum 25mm Momentary/Latching Pin Terminal appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting size for industrial panel universal installation
• STOP symbol red mushroom head, clear emergency visual warning
• Metal and plastic two bezel materials optional for different needs
• Fast acting flat jump contact structure, short stroke and quick response
• Multiple position modes: maintained & momentary optional
• Protection grade: standard IP40, optional IP65 waterproof version
• Compliant with IEC60947-5-1 and GB/T 14048.5 industrial safety standards
• High rated insulation voltage up to 690V for safe circuit isolation
• 10A conventional freeair thermal current, boxed type 6A
• Complete AC-15 / DC-13 load specifications for multiple voltage systems
• Premium brass / gold / silver optional contact material
• Ultra-long mechanical life up to 1 million times for mushroom head type
• Spiral embedded terminal, support multi-spec wire wiring
• Compact structure, suitable for high-frequency working scenarios
• Non-illuminated design, stable mechanical performance

Product Attributes

• Bezel: Metal , Plastic
• Head Type: Mushroom
• Lamp: Non Illuminated
• Contact Material: Brass , Gold , Silver
• Position Mode: Two / Three Position Maintained & Momentary Optional

Product Advantages

This 22mm STOP symbol mushroom maintained emergency switch adopts fast flat jump contact structure with short action stroke and fast response speed. It supports metal and plastic bezel optional, standard IP40 protection and optional IP65 waterproof version. Comply with IEC60947-5-1 and GB/T 14048.5 safety standards, 690V high insulation voltage and complete AC/DC load parameters. Mushroom head model reaches 1 million times mechanical life, durable for high frequency use. Spiral embedded terminal supports multi-spec wire wiring, easy installation and stable connection, ideal for industrial high-frequency equipment and safety control systems.

Applications

• 22mm STOP symbol mushroom head maintained emergency stop for industrial panel
• High-frequency working machinery and production line safety protection switch
• Automation equipment CNC machine tool emergency cutoff button
• Indoor workshop IP40 conventional environment control panel switch
• IP65 waterproof version for humid workshop and light industrial site

FAQ

1. What is the mounting size?
Standard 22mm mounting hole, suitable for conventional industrial panel installation.

2. What protection levels are available?
Standard IP40, IP65 waterproof version is optional for wet environments.

3. What is the mechanical life?
Mushroom head type up to 1 million times, suitable for high frequency operation.

4. What material options are there?
Bezel available in metal and plastic; contact optional brass, gold, silver.

5. What standards does it comply with?
Meets IEC60947-5-1 and GB/T 14048.5 industrial safety standards.

6. What wiring wire size is supported?
Adaptable 0.5mm² to 2.5mm² wire with spiral embedded terminal.

7. What working scenarios is it for?
Perfect for high-frequency industrial machinery, automation lines, machine tools and indoor workshop safety control.

The post Stop Symbol 22mm Metal Bezel Mushroom Maintained Emergency Push Botton Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for universal industrial panel installation
• Classic stop symbol red mushroom head for obvious emergency identification
• Metal and plastic dual bezel material optional to match different needs
• Fast acting flat jump contact structure, short stroke and quick response
• Suitable for high-frequency working scenarios with stable performance
• Multiple position modes: 2-position / 3-position maintained & momentary optional
• Standard IP40 protection grade, IP65 waterproof version optional
• High rated insulation voltage up to 690V for electrical safety isolation
• Conventional thermal current 10A, boxed type rated 6A
• Complete AC-15 and DC-13 voltage and current load specifications
• Contact material optional: Brass, Gold, Silver
• Mushroom head mechanical life up to 1 million times
• Long electrical life: AC 500,000 times, DC 200,000 times
• Spiral embedded terminal supports multiple wire gauge wiring
• Working temperature range: -5℃ ~ 40℃
• Complies with IEC60947-5-1 and GB/T 14048.5 industrial safety standards
• Non-illuminated design, simple and compact structure

Product Attributes

• Bezel: Metal , Plastic
• Head Type: Mushroom
• Lamp: Non Illuminated
• Contact Material: Brass , Gold , Silver
• Position Mode: Two / Three Position Maintained & Momentary Optional

Product Advantages

This 22mm stop symbol mushroom maintained emergency switch is designed with fast flat jump contact structure, featuring short action stroke and fast response speed, perfectly suitable for high-frequency industrial use. It provides metal and plastic bezel options, standard IP40 protection and optional IP65 waterproof version for humid environments. With 690V high insulation voltage and complete AC/DC load parameters, it meets various power system requirements. Mushroom head achieves 1 million mechanical service life, durable for long-term frequent operation. Spiral embedded terminal supports multi-spec wiring, complies with international safety standards, compact and reliable for industrial safety control.

Applications

• 22mm stop symbol mushroom head maintained emergency stop for industrial control panel
• High-frequency production line and automation equipment safety emergency switch
• CNC machine tools and mechanical equipment instant power cutoff button
• Indoor workshop IP40 conventional environment safety protection button
• IP65 waterproof version for humid factory and light industrial sites

FAQ

1. What is the mounting size?
Standard 22mm mounting aperture, fits most industrial control panels.

2. What protection levels are available?
Default IP40, IP65 waterproof version is optional for damp and dusty environments.

3. What operation positions does it support?
Supports two-position and three-position, maintained and momentary multiple modes.

4. What is the service life?
Mushroom head mechanical life up to 1 million times, electrical life AC 500,000 / DC 200,000 times.

5. What contact materials can I choose?
Optional brass, gold and silver contact materials for different conductivity needs.

6. What wire size is supported?
Spiral terminal fits wire gauge from 0.5mm² to 2.5mm².

7. What scenarios is it suitable for?
Ideal for high-frequency production lines, machine tools, automation equipment, indoor workshops and optional waterproof industrial occasions.

The post 22mm Stop Symbol Mushroom Maintained Emergency Push Botton Switches appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for industrial control panel universal installation
• Oversized big mushroom head design, obvious emergency recognition and easy operation
• Metal and plastic two bezel materials optional for different installation environments
• Fast acting flat jump contact group, short stroke and ultra-fast response
• Suitable for high-frequency working cycle with stable mechanical performance
• Multiple position modes: 2-position / 3-position maintained & momentary optional
• Protection grade default IP40, support customized IP65 waterproof version
• Rated insulation voltage up to 690V for high voltage safety isolation
• Conventional freeair thermal current 10A, boxed type 6A
• Complete AC-15 & DC-13 voltage and current load specifications
• Contact optional: Brass, Gold, Silver for different conductivity demands
• Mushroom head mechanical life up to 1 million times
• Electrical life: AC 500,000 times; DC 200,000 times
• Spiral embedded terminal fits 0.5mm² ~ 2.5mm² wire range
• Working temperature: -5℃ ~ 40℃ for indoor industrial environment
• Complies with IEC60947-5-1 and GB/T 14048.5 industrial safety standards
• Non-illuminated compact structure, durable for long-term use

Product Attributes

• Bezel: Metal , Plastic
• Head Type: Mushroom Big Head
• Lamp: Non Illuminated
• Contact Material: Brass , Gold , Silver
• Position Mode: Two / Three Position Maintained & Momentary Optional

Product Advantages

This 22mm big head mushroom maintained emergency button adopts oversized mushroom head design for clearer emergency identification. Built with fast flat jump contact structure, short action stroke and fast response speed, perfectly matching high-frequency working scenarios. Metal and plastic bezel optional, default IP40 protection and optional IP65 waterproof version. 690V high insulation voltage and complete AC/DC load parameters adapt to various industrial power systems. Mushroom head reaches 1 million mechanical life, with long electrical service life. Spiral embedded terminal supports multi-spec wiring, complies with international safety standards, compact and durable for industrial long-term operation.

Applications

• 22mm big head mushroom maintained emergency stop for industrial control panel
• High-frequency production line automation equipment safety cutoff switch
• CNC machine tool and mechanical engineering equipment emergency button
• Indoor workshop IP40 conventional environment safety protection switch
• IP65 waterproof version for humid factory workshop and industrial site

FAQ

1. What is the mounting size?
Standard 22mm mounting aperture, suitable for most industrial panel installation.

2. Does it have waterproof option?
Standard IP40, customized IP65 waterproof version is available for damp environments.

3. What operation modes are available?
Supports two-position and three-position, maintained and momentary multiple options.

4. What is the service life?
Mushroom head mechanical life up to 1 million times, AC 500,000 / DC 200,000 electrical life.

5. What contact materials can be chosen?
Optional brass, gold, silver contact to meet different conduction requirements.

6. What wire size does it support?
Spiral terminal supports 0.5mm² to 2.5mm² wire connection.

7. Where is it mainly used?
Suitable for high-frequency production lines, machine tools, automation equipment, indoor workshops and optional waterproof industrial occasions.

The post 22mm Big Head Mushroom Maintained Emergency Push Botton Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for industrial panel universal installation
• Metal mushroom head design with obvious STOP identification for emergency operation
• Metal and plastic dual bezel optional for different installation environments
• Fast acting flat jump contact structure, compact body with short action stroke
• Quick response performance, specially designed for high-frequency working scenarios
• Multiple position modes: 2-position / 3-position maintained & momentary optional
• Default IP40 protection grade, IP65 waterproof version can be customized
• High 690V rated insulation voltage for reliable electrical isolation
• Conventional thermal current 10A, boxed type rated 6A
• Complete AC-15 & DC-13 load specifications adapt to multiple voltage systems
• Contact material optional: Brass, Gold, Silver
• Mushroom head mechanical life up to 1 million times
• Electrical life: AC 500,000 times / DC 200,000 times
• Spiral embedded terminal, wiring range 0.5mm² ~ 2.5mm²
• Working temperature range: -5℃ ~ 40℃
• Complies with IEC60947-5-1 and GB/T 14048.5 industrial safety standards
• Non-illuminated type, stable and durable for long-term industrial use

Product Attributes

• Bezel: Metal , Plastic
• Head Type: Mushroom
• Lamp: Non Illuminated
• Contact Material: Brass , Gold , Silver
• Position Mode: Two / Three Position Maintained & Momentary Optional

Product Advantages

This 22mm metal mushroom maintained emergency stop switch adopts fast flat jump contact design, compact structure with short stroke and fast response, perfectly suitable for high-frequency industrial occasions. It supports metal and plastic bezel selection, standard IP40 protection and customizable IP65 waterproof version for humid workshops. 690V high insulation voltage and complete AC/DC load parameters meet various industrial power demands. Multiple contact materials optional, mushroom head reaches 1 million mechanical life, long electrical service life. Spiral embedded terminal is easy for wiring, fully compliant with international industrial safety standards, stable and reliable for long-term safety protection.

Applications

• 22mm metal mushroom head maintained emergency stop for industrial control panel
• High-frequency automation production line safety emergency cutoff switch
• CNC machine tools and mechanical equipment dedicated protection button
• Indoor workshop IP40 conventional environment safety control switch
• IP65 customized version for wet and dusty industrial sites

FAQ

1. What is the mounting diameter?
Standard 22mm mounting hole, compatible with most industrial control panel reserved holes.

2. Is waterproof version available?
Standard IP40, support customized IP65 waterproof model for humid environments.

3. What operation modes are supported?
Two-position and three-position, maintained and momentary multiple optional modes.

4. What is the service life?
Mushroom head mechanical life up to 1 million times, AC 500,000 / DC 200,000 times electrical life.

5. What contact materials can I choose?
Optional brass, gold and silver to meet different conductivity requirements.

6. What wire gauge is suitable?
Spiral embedded terminal fits 0.5mm² to 2.5mm² wires.

7. What are the common application scenarios?
Widely used in high-frequency production lines, machine tools, automation equipment, indoor workshops and customized waterproof industrial sites.

The post 22mm Metal Head Mushroom Maintained Emergency Stop Switches appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for universal industrial panel installation
• Non-illuminated pure mechanical design, stable without light failure
• Metal head design with multiple head types optional
• Transparent high-strength PBT base, clear internal structure visible
• Momentary self-resetting operation type for emergency control
• Rich shell length options to fit different panel thickness
• Default IP40 protection grade, IP65 waterproof version customizable
• Fast flat jump contact structure, short stroke fast response
• Rated insulation voltage up to 690V for high voltage isolation
• Conventional thermal current 10A, boxed type rated 6A
• Complete AC-15 / DC-13 voltage and current load parameters
• Contact optional: Brass, Gold, Silver for different demands
• Mushroom & flat head mechanical life up to 1 million times
• Long electrical life: AC 500,000 / DC 200,000 times
• Spiral embedded terminal, wiring range 0.5mm² ~ 2.5mm²
• Working temperature: -5℃ ~ 40℃ for indoor industrial use
• Complies with IEC60947-5-1 and GB/T 14048.5 standards

                                                                                                    without LED                                                              with LED

Product Attributes

• Lamp: Non Illuminated
• Head Type: Domed, Flat, High Round, Key, Mushroom, Rotary, Square
• Position Mode: Two / Three Position Maintained & Momentary
• Contact Material: Brass , Gold , Silver
• Shell Length: 8mm,9mm,10mm,12mm,13mm,16mm,17mm,17.5mm,18mm

Product Advantages

This 22mm non-illuminated metal head momentary emergency stop switch adopts high-strength transparent PBT base with clear internal view and sturdy structure. Multiple head styles and shell lengths are optional to meet different panel installation needs. Momentary self-resetting design is suitable for instant emergency control. IP40 default protection and optional IP65 waterproof adapt to various environments. With 690V high insulation voltage and complete AC/DC load specifications, optional brass/gold/silver contacts match different conductivity requirements. Long mechanical and electrical service life, spiral embedded wiring is convenient and reliable, fully compliant with industrial safety standards.

Applications

• 22mm non-illuminated momentary metal head industrial emergency stop button
• High-frequency automation production line self-resetting safety switch
• CNC machine tools and mechanical equipment emergency control button
• Indoor workshop IP40 conventional environment safety protection
• IP65 customized version for humid factory and dust workshop

FAQ

1. What is the mounting size?
Standard 22mm mounting hole, fits most industrial control panels.

2. Is this illuminated type?
No, it is non-illuminated pure mechanical momentary emergency switch.

3. What head styles are available?
Domed, Flat, High Round, Key, Mushroom, Rotary, Square multiple options.

4. Can I choose shell length?
Yes, many shell lengths from 8mm to 18mm are optional.

5. What protection levels are available?
Standard IP40, IP65 waterproof version can be customized.

6. What contact materials can I pick?
Optional Brass, Gold, Silver contact for different usage needs.

7. What working scenarios is it suitable for?
Ideal for machine tools, automation lines, indoor workshops and optional waterproof industrial sites.

The post Non Illuminated 22mm Metal Head Momentary Emergency Stop Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for industrial control panel universal installation
• Dual-purpose design: Rotary knob control + emergency stop function
• Non-illuminated pure mechanical type, stable without light failure risk
• High-strength transparent PBT base, internal structure clearly visible
• Long handle and short handle multiple styles for selection
• Plastic and SUS304 stainless steel two shell material optional
• Rich shell length sizes to match different panel thickness
• Multiple position modes: 2-position / 3-position maintained & momentary
• Default IP40 protection grade, customizable IP65 waterproof version
• Rated insulation voltage up to 690V for high voltage safety isolation
• 10A conventional thermal current, boxed type rated 6A
• Complete AC-15 / DC-13 industrial load specification
• Contact material optional: Brass, Gold, Silver
• Mushroom & flat head mechanical life up to 1 million times
• Electrical life: AC 500,000 times; DC 200,000 times
• Spiral embedded terminal, wiring range 0.5mm² ~ 2.5mm²
• Working temperature -5℃ ~ 40℃, suitable for indoor industrial environment
• Complies with IEC60947-5-1 and GB/T 14048.5 safety standards

            Short Handle                                                                            Short Handle with LED                                                          Long Handle

Product Attributes

• Lamp: Non Illuminated
• Shell Material: Plastic , SUS304
• Contact Material: Brass , Gold , Silver
• Position Mode: Two / Three Position Maintained & Momentary
• Shell Length: 8mm,9mm,10mm,12mm,13mm,16mm,17mm,17.5mm,18mm

Product Advantages

This 22mm non-illuminated rotary knob switch integrates knob selection and emergency stop function in one unit. Adopts transparent high-strength PBT base with sturdy structure and clear internal view. Supports long and short handle options, plastic and SUS304 stainless steel shell optional, plus multiple shell lengths to fit various panel thickness. Multiple two-position and three-position operation modes meet diverse circuit control needs. Standard IP40 protection with customizable IP65 waterproof version, 690V high insulation voltage and complete AC/DC load parameters. Optional brass, gold and silver contacts ensure stable conduction, long mechanical and electrical service life, suitable for long-term high-frequency industrial use.

Applications

• 22mm non-illuminated rotary knob switch for industrial control panel
• Machine tool and automation equipment gear selection control switch
• Production line dual-use rotary regulation & emergency stop button
• Electrical cabinet IP40 conventional environment selector switch
• IP65 waterproof version for humid workshop and dust industrial sites

FAQ

1. What is the mounting size?
Standard 22mm mounting hole, fits most industrial control panel reserved openings.

2. Is this switch dual-purpose?
Yes, it combines rotary knob selection and emergency stop function in one.

3. Is it illuminated type?
No, it is non-illuminated pure mechanical rotary switch.

4. What shell materials are available?
Plastic and SUS304 stainless steel two options.

5. What protection level does it have?
Standard IP40, IP65 waterproof version can be customized.

6. What contact choices are there?
Optional brass, gold and silver contact materials for different needs.

7. What scenarios is it suitable for?
Widely used in machine tools, automation lines, electrical cabinets for gear switching and emergency stop control.

The post 22mm Rotary Switch Non Illuminated Knob Switch And Emergency Stop Switches appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for industrial panel universal installation
• Key lock design for permission control and anti-misoperation
• High-strength transparent PBT base with clear internal structure visible
• Plastic and SUS304 stainless steel two shell material optional
• Multiple shell length options fit different panel thickness requirements
• Rich position modes: 2-position / 3-position maintained & momentary
• Default IP40 protection grade, IP65 waterproof version customizable
• Rated insulation voltage up to 690V for high voltage safety isolation
• Conventional thermal current 10A, boxed type rated 6A
• Complete AC-15 & DC-13 voltage and current load specifications
• Contact optional: Brass, Gold, Silver for different conduction needs
• Flat & mushroom head mechanical life up to 1 million times
• Electrical life: AC 500,000 times / DC 200,000 times
• Spiral embedded terminal, wiring range 0.5mm² ~ 2.5mm²
• Working temperature: -5℃ ~ 40℃ for indoor industrial environment
• Complies with IEC60947-5-1 and GB/T 14048.5 safety standards

Product Attributes

• Shell Material: Plastic , SUS304
• Contact Material: Brass , Gold , Silver
• Position Mode: Three Position Left Maintained And Right Momentary , Three Position Maintained , Three Position Momentary, Two Position Maintained , Two Position Momentary
• Shell Length: 8mm,9mm,10mm,12mm,13mm,16mm,17mm,17.5mm,18mm

Product Advantages

This 22mm key emergency stop switch adopts key lock structure to effectively prevent misoperation and realize authority management. Equipped with transparent high-strength PBT base, stable and durable with clear internal structure. Plastic and SUS304 stainless steel shell optional, multiple shell lengths adapt to various panel thickness. Multiple two-position and three-position working modes meet complex circuit control demands. Standard IP40 protection with customizable IP65 waterproof version for humid and dusty workshops. 690V high insulation voltage and complete AC/DC load parameters match most industrial power systems. Optional multi-contact material and long mechanical life make it ideal for long-term frequent use.

Applications

• 22mm key lock emergency stop switch for industrial control panel
• Equipment permission lock key selector switch for machine tools
• Automation equipment key control safety emergency stop button
• Electrical cabinet dedicated key switch with safety protection function
• IP65 waterproof version for humid factory and dust workshop scenarios

FAQ

1. What is the mounting size?
Standard 22mm mounting hole, suitable for most industrial control panels.

2. Does it have key lock function?
Yes, built-in key lock design to prevent misoperation and manage access rights.

3. What shell materials are available?
Plastic and SUS304 stainless steel two optional materials.

4. Can I customize waterproof version?
Default IP40, support customized IP65 waterproof version for harsh environments.

5. What contact options are there?
Optional brass, gold and silver contact to meet different conductivity requirements.

6. What position modes does it support?
Supports two-position and three-position, maintained and momentary multiple modes.

7. Where is it commonly used?
Suitable for machine tools, automation equipment, electrical cabinets requiring key permission lock and emergency stop protection.

The post 22mm Key Switch Emergency Stop Switches appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.

• Standard 22mm mounting hole for universal industrial panel installation
• Red non-illuminated momentary emergency stop design for safety control
• High-strength transparent PBT base, sturdy with visible internal structure
• Multiple head types optional: Domed, Flat, Flat With Chamfer, High Round, Key, Mushroom, Rotary, Square
• Various shell length sizes fit different panel thickness requirements
• Multiple position modes: 2-position / 3-position maintained & momentary
• Default IP40 protection grade, customizable IP65 waterproof version
• Rated insulation voltage up to 690V for high voltage safety isolation
• Conventional thermal current 10A, boxed type rated 6A
• Complete AC-15 & DC-13 voltage and current load specifications
• Contact material optional: Brass, Gold, Silver
• Flat & mushroom head mechanical life up to 1 million times
• Electrical life: AC 500,000 times; DC 200,000 times
• Spiral embedded terminal supports 0.5mm² ~ 2.5mm² wiring
• Working temperature range: -5℃ ~ 40℃
• Complies with IEC60947-5-1 and GB/T 14048.5 industrial standards
• Pure mechanical non-illuminated design, stable and failure-free

Product Attributes

• Lamp: Non Illuminated
• Head Color: Red
• Head Type: Domed , Flat , Flat With Chamfer , High Round , Key , Mushroom, Rotary , Square
• Position: Three Position Left Maintained And Right Momentary , Three Position Maintained , Three Position Momentary, Two Position Maintained , Two Position Momentary
• Contact Material: Brass , Gold , Silver
• Length of Shell: 8mm,9mm,10mm,12mm,13mm,16mm,17mm,17.5mm,18mm

Product Advantages

This 22mm red non-illuminated momentary emergency stop switch adopts high-strength transparent PBT base with solid structure and clear internal view. Red classic emergency color design with multiple head types and shell lengths for free combination. Supports various two-position and three-position operation modes to meet complex circuit demands. Standard IP40 protection and customizable IP65 waterproof version adapt to dusty and humid workshops. 690V high insulation voltage and complete AC/DC load parameters match most industrial power systems. Optional multi-contact material and ultra-long mechanical life ensure stable performance for high-frequency long-term use.

Applications

• 22mm red non-illuminated momentary emergency stop button for control panel
• Industrial automation production line high-frequency safety protection switch
• CNC machine tool and mechanical equipment instant reset emergency button
• Indoor workshop IP40 conventional environment safety control device
• IP65 waterproof customized version for humid and dusty industrial sites

FAQ

1. What is the mounting size?
Standard 22mm mounting hole, compatible with all conventional 22mm control panels.

2. Is it illuminated type?
No, it is non-illuminated pure mechanical momentary emergency switch.

3. Are there multiple head options?
Yes, Domed, Flat, Mushroom, Rotary and many other head types optional.

4. Can I choose shell length?
Multiple shell lengths from 8mm to 18mm are available for different panel thickness.

5. What protection levels are available?
Standard IP40, IP65 waterproof version can be customized for wet environments.

6. What contact materials can I choose?
Optional Brass, Gold, Silver to meet different conductivity needs.

7. What application scenarios is it suitable for?
Widely used in machine tools, automation lines, electrical cabinets, indoor workshops and optional waterproof industrial occasions.

The post Non Illuminated 22mm Red Momentary Emergency Stop Switch appeared first on Ruggedized Metal Push Buttons & Professional Control Switches.
